groupProj. UProj. WSCorr. UCorr. WS BLLCMPos. angler MU MP

11271 165.54 881.73 88.28 470.92 17.90 60.25 19.05 302.54 0.3713 -66.0 -26.0


previous   or   next   observation for the same group / back to the solar disc

SDO HMI 2011-08-23 07:59:09 UT
No observation available
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)


spotProj. UProj. WSCorr. UCorr. WSBLLCMPos. angler MU MP

1 0.00 1.89 0.00 1.03 13.15 65.26 24.06 286.54 0.4159 -840.0 -631.5
2 1.71 3.78 0.94 2.09 18.69 65.28 24.08 298.88 0.4432 876.9 731.7
3 27.96 168.03 15.22 91.50 16.26 64.35 23.15 294.35 0.4161 -1285.2 -395.8
4 1.26 4.77 0.68 2.56 12.64 63.69 22.49 286.12 0.3901 -865.5 -804.4
5 0.00 2.25 0.00 1.20 7.95 63.24 22.04 273.98 0.3741 -835.0 -598.8
6 0.00 2.70 0.00 1.45 13.01 63.59 22.39 287.11 0.3899 -724.0 -720.2
7 0.45 -3.00 0.24 -3.00 16.04 63.78 22.58 294.30 0.4066 -1122.0 999999
8 0.00 3.51 0.00 1.88 13.46 63.26 22.06 288.42 0.3866 -850.0 -640.9
9 0.00 0.99 0.00 0.53 13.77 63.15 21.96 289.26 0.3863 -737.0 -656.8
10 0.00 0.99 0.00 0.53 13.59 63.00 21.80 288.92 0.3833 -1042.0 -878.5
11 0.00 2.34 0.00 1.26 16.93 63.23 22.04 296.81 0.4039 -822.0 -631.5
12 0.00 2.61 0.00 1.40 15.35 62.75 21.55 293.49 0.3878 -1013.0 -732.7
13 2.61 14.21 1.41 7.64 16.54 62.85 21.65 296.27 0.3960 -857.7 -823.2
14 0.00 1.62 0.00 0.88 18.95 63.16 21.96 301.40 0.4160 -870.0 -697.8
15 0.00 0.90 0.00 0.48 15.05 62.48 21.28 292.98 0.3823 -950.0 -745.3
16 29.22 94.58 15.76 51.05 17.33 62.60 21.40 298.33 0.3974 -1198.0 -457.6
17 7.55 -13.00 4.06 -13.00 16.50 62.43 21.23 296.54 0.3898 -1064.5 999999
18 1.17 -16.00 0.63 -16.00 17.82 62.56 21.36 299.51 0.4001 -810.3 999999
19 0.00 3.42 0.00 1.85 18.30 62.35 21.15 300.80 0.4004 -955.0 -620.8
20 0.00 1.53 0.00 0.82 18.05 62.31 21.12 300.27 0.3983 -666.0 -570.9
21 1.44 2.70 0.78 1.47 20.10 62.49 21.29 304.56 0.4158 -837.3 -847.6
22 0.00 1.89 0.00 1.01 17.51 61.84 20.64 299.53 0.3880 -930.0 -715.9
23 0.00 9.98 0.00 5.34 17.34 61.41 20.21 299.58 0.3809 -525.0 -885.9
24 0.00 1.71 0.00 0.92 17.75 61.43 20.23 300.52 0.3839 -875.0 -641.4
25 0.00 0.99 0.00 0.53 19.10 61.59 20.39 303.43 0.3963 -965.0 -792.0
26 0.00 1.62 0.00 0.87 18.86 61.43 20.23 303.09 0.3921 -1042.0 -789.6
27 0.00 0.81 0.00 0.45 25.26 62.30 21.10 314.61 0.4592 -881.0 -689.0
28 0.54 6.83 0.29 3.66 17.94 61.18 19.98 301.26 0.3819 -1160.2 -804.2
29 1.26 1.53 0.68 0.82 18.91 60.99 19.79 303.71 0.3867 -1100.3 -909.7
30 0.00 0.90 0.00 0.49 20.34 61.10 19.90 306.71 0.3999 -623.0 -541.0
31 1.62 3.60 0.87 1.93 19.10 60.91 19.71 304.24 0.3871 -967.4 -669.4
32 0.00 1.44 0.00 0.77 17.19 60.69 19.49 300.01 0.3696 -1018.0 -841.3
33 0.36 -31.00 0.19 -31.00 19.26 60.89 19.70 304.60 0.3882 -862.5 999999
34 0.00 2.07 0.00 1.11 20.00 60.92 19.72 306.22 0.3947 -1097.0 -796.2
35 0.00 1.17 0.00 0.62 18.05 60.68 19.48 302.09 0.3759 -576.0 -505.2
36 0.00 3.24 0.00 1.75 20.41 60.94 19.74 307.06 0.3984 -597.0 -604.9
37 0.00 1.71 0.00 0.91 17.47 60.58 19.38 300.81 0.3702 -852.0 -717.3
38 0.00 0.45 0.00 0.24 15.76 60.30 19.10 296.81 0.3544 433.0 451.6
39 0.00 0.81 0.00 0.43 15.55 60.08 18.88 296.50 0.3499 635.0 533.0
40 0.00 11.33 0.00 6.10 20.39 60.56 19.36 307.51 0.3934 -901.0 -858.3
41 0.00 1.44 0.00 0.78 20.87 60.42 19.22 308.71 0.3959 -737.0 -554.4
42 0.00 1.71 0.00 0.92 20.47 60.13 18.93 308.26 0.3886 -895.0 -721.0
43 4.23 19.60 2.24 10.37 16.95 59.69 18.49 300.59 0.3539 -962.0 -271.3
44 0.00 0.99 0.00 0.51 9.16 58.90 17.70 278.31 0.3046 -761.0 -604.5
45 0.00 0.63 0.00 0.33 8.04 58.68 17.48 274.66 0.2998 -850.0 -714.4
46 1.53 17.62 0.82 9.44 20.81 59.42 18.22 309.97 0.3829 -622.6 -781.5
47 0.99 387.32 0.53 205.38 19.49 58.82 17.62 307.90 0.3632 506.7 314.0
48 0.00 2.43 0.00 1.27 15.98 58.46 17.26 299.56 0.3294 928.0 779.1
49 0.00 1.62 0.00 0.85 16.38 58.40 17.20 300.73 0.3315 844.0 709.3
50 11.15 -47.00 5.88 -47.00 18.23 58.35 17.15 305.60 0.3459 1308.7 999999
51 0.81 -47.00 0.43 -47.00 19.38 58.47 17.27 308.16 0.3577 810.9 999999
52 0.00 1.53 0.00 0.80 16.08 58.01 16.81 300.45 0.3238 905.0 721.7
53 1.44 -47.00 0.76 -47.00 18.55 58.21 17.01 306.56 0.3469 1285.7 999999
54 34.07 -47.00 18.02 -47.00 19.07 58.23 17.03 307.80 0.3519 1311.8 999999
55 0.72 -47.00 0.38 -47.00 18.33 58.12 16.92 306.17 0.3438 1068.1 999999
56 11.60 -47.00 6.17 -47.00 20.38 58.24 17.04 310.78 0.3644 1069.4 999999
57 0.00 1.35 0.00 0.72 20.11 57.98 16.78 310.59 0.3585 96.0 73.4
58 0.00 1.98 0.00 1.05 19.96 57.86 16.66 310.43 0.3555 785.0 553.7
59 2.61 18.16 1.37 9.56 18.94 57.58 16.38 308.48 0.3423 1111.3 883.7
60 0.00 3.33 0.00 1.76 20.15 57.68 16.48 311.15 0.3552 687.0 576.1
61 0.00 1.17 0.00 0.61 18.11 57.44 16.24 306.66 0.3327 161.0 146.3
62 0.00 4.05 0.00 2.14 20.10 57.23 16.04 311.77 0.3493 858.0 723.2
63 0.00 2.43 0.00 1.28 19.93 56.95 15.75 311.84 0.3440 877.0 752.0
64 0.00 1.35 0.00 0.69 6.28 55.95 14.75 268.18 0.2543 -820.0 -646.7
65 9.62 17.53 4.97 9.05 13.93 56.21 15.01 296.49 0.2822 1108.4 656.2
66 0.00 1.44 0.00 0.76 21.00 56.66 15.46 314.73 0.3518 758.0 586.2
67 0.00 1.71 0.00 0.87 7.62 55.64 14.44 273.53 0.2488 834.0 686.1
68 0.00 1.89 0.00 1.00 20.88 56.44 15.24 314.85 0.3480 785.0 655.0
69 0.00 2.16 0.00 1.14 20.66 56.39 15.19 314.48 0.3450 991.0 828.5
70 7.19 14.30 3.71 7.37 14.04 55.80 14.60 297.42 0.2767 1092.1 741.1
71 2.43 -70.00 1.25 -70.00 13.83 55.79 14.59 296.73 0.2750 988.4 999999
72 0.00 3.96 0.00 2.03 13.93 55.34 14.14 297.75 0.2692 909.0 733.4
73 0.00 1.62 0.00 0.85 20.58 54.84 13.64 317.22 0.3264 976.0 794.8
74 0.00 1.17 0.00 0.60 14.64 52.91 11.71 304.68 0.2399 882.0 745.7
75 0.00 0.81 0.00 0.42 21.70 52.74 11.54 324.08 0.3182 577.0 579.9
76 0.00 1.53 0.00 0.80 21.74 52.41 11.21 324.92 0.3155 804.0 692.6


  		• Proj. U -  Projected umbra area in millionths of solar disc, negative values indicate
    that the umbra consists of fragmented regions which cannot be separated without losing umbral area.
    In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that
    the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2.
  		• Proj. WS -  Projected whole spot area in millionths of solar disc, negative values indicate
    that several umbras have a common penumbra, e.g. -7 means that the given umbra shares
    a penumbra with umbra No.7, and the WS value is indicated at No.7.
  		• Corr. U -  Corrected umbra area in millionths of solar hemisphere, for negative values see above
  		• Corr. WS -  Corrected whole spot area in millionths of solar hemisphere, for negative values see above
  		• B -  Heliographic latitude B; positive: North, negative: South
  		• L -  Heliographic longitude L
  		• LCM -  Longitudinal distance from the Sun's central meridian
  		• Pos. angle -  Position angle
  		• r -  Distance from the centre of Sun's disc in terms of Sun's radius
  		• MU -  Mean magnetic field within the umbra contour averaged the pixel values with sign.
  		• MP -  Mean magnetic field within the penumbra contour averaged the pixel values with sign.
