SDO HMI 2011-08-24 10:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.43 | 24.46 | 1.45 | 15.22 | 7.50 | 348.95 | -37.39 | 86.86 | 0.6034 | -226.8 | -212.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-24 10:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.07 | 0.00 | 1.22 | 7.83 | 353.07 | -33.27 | 86.39 | 0.5466 | 616.0 | 384.3 | |
| 0.00 | 1.89 | 0.00 | 1.12 | 7.20 | 352.35 | -33.98 | 87.50 | 0.5572 | -708.0 | -557.8 | |
| 2.43 | 8.98 | 1.45 | 5.37 | 7.06 | 352.03 | -34.31 | 87.74 | 0.5619 | -817.8 | -733.8 | |
| 0.00 | 0.90 | 0.00 | 0.54 | 8.39 | 351.46 | -34.88 | 85.36 | 0.5697 | -591.0 | -440.1 | |
| 0.00 | 1.26 | 0.00 | 0.76 | 7.05 | 351.48 | -34.86 | 87.71 | 0.5699 | -671.0 | -486.2 | |
| 0.00 | 1.08 | 0.00 | 0.67 | 7.00 | 349.48 | -36.86 | 87.67 | 0.5981 | -606.0 | -583.3 | |
| 0.00 | 0.90 | 0.00 | 0.56 | 6.95 | 349.25 | -37.09 | 87.73 | 0.6013 | -576.0 | -503.8 | |
| 0.00 | 1.08 | 0.00 | 0.68 | 7.02 | 348.09 | -38.25 | 87.54 | 0.6173 | -681.0 | -636.1 | |
| 0.00 | 1.17 | 0.00 | 0.77 | 6.67 | 344.44 | -41.90 | 87.82 | 0.6661 | -551.0 | -328.8 | |
| 0.00 | 1.26 | 0.00 | 0.84 | 7.39 | 343.90 | -42.44 | 86.70 | 0.6726 | 701.0 | 553.7 | |
| 0.00 | 1.35 | 0.00 | 0.91 | 8.29 | 342.95 | -43.39 | 85.33 | 0.6843 | 604.0 | 461.8 | |
| 0.00 | 2.52 | 0.00 | 1.78 | 9.28 | 340.28 | -46.06 | 83.84 | 0.7170 | 825.0 | 663.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
