SDO HMI 2011-08-25 10:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 73.49 | 418.03 | 54.38 | 310.11 | 17.61 | 61.09 | 47.96 | 287.50 | 0.7440 | -107.0 | -9.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-25 10:59:09 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.72 | 0.00 | 0.59 | 16.65 | 66.22 | 53.09 | 285.60 | 0.7976 | 312.0 | 247.6 | |
| 0.00 | 1.08 | 0.00 | 0.86 | 14.72 | 65.24 | 52.12 | 283.23 | 0.7864 | 491.0 | 350.9 | |
| 0.00 | 1.35 | 0.00 | 1.07 | 14.84 | 64.88 | 51.75 | 283.42 | 0.7827 | 684.0 | 586.5 | |
| 18.95 | 108.04 | 15.00 | 85.64 | 16.63 | 64.70 | 51.58 | 285.72 | 0.7821 | -953.6 | -200.6 | |
| 0.00 | 4.13 | 0.00 | 3.19 | 13.78 | 63.73 | 50.61 | 282.10 | 0.7699 | -530.0 | -483.3 | |
| 0.00 | 1.17 | 0.00 | 0.90 | 13.78 | 63.39 | 50.26 | 282.12 | 0.7662 | -566.0 | -430.4 | |
| 0.00 | 1.08 | 0.00 | 0.81 | 15.20 | 62.41 | 49.29 | 284.06 | 0.7563 | -484.0 | -464.8 | |
| 1.98 | 11.41 | 1.50 | 8.66 | 16.30 | 62.54 | 49.41 | 285.51 | 0.7587 | -623.5 | -492.4 | |
| 0.00 | 3.59 | 0.00 | 2.70 | 15.53 | 62.18 | 49.05 | 284.52 | 0.7541 | -764.0 | -642.8 | |
| 11.32 | 39.34 | 8.58 | 29.93 | 17.37 | 62.47 | 49.35 | 286.92 | 0.7591 | -855.0 | -137.7 | |
| 0.00 | 1.08 | 0.00 | 0.81 | 16.71 | 62.14 | 49.02 | 286.09 | 0.7548 | -774.0 | -603.2 | |
| 1.26 | -10.00 | 0.95 | -10.00 | 17.66 | 62.34 | 49.21 | 287.32 | 0.7580 | -779.1 | 999999 | |
| 2.42 | 2.78 | 1.83 | 2.11 | 18.20 | 62.25 | 49.12 | 288.05 | 0.7577 | -651.3 | -516.2 | |
| 0.00 | 4.04 | 0.00 | 2.99 | 17.42 | 61.23 | 48.11 | 287.15 | 0.7456 | -682.0 | -573.5 | |
| 0.00 | 4.22 | 0.00 | 3.10 | 17.37 | 60.69 | 47.57 | 287.16 | 0.7395 | -802.0 | -643.0 | |
| 0.00 | 1.26 | 0.00 | 0.91 | 17.03 | 60.01 | 46.89 | 286.79 | 0.7314 | -572.0 | -435.4 | |
| 0.00 | 1.35 | 0.00 | 0.98 | 17.91 | 60.27 | 47.14 | 287.96 | 0.7355 | -643.0 | -573.0 | |
| 0.00 | 0.72 | 0.00 | 0.53 | 20.04 | 61.03 | 47.90 | 290.68 | 0.7473 | -607.0 | -513.2 | |
| 0.00 | 1.17 | 0.00 | 0.85 | 18.99 | 60.42 | 47.30 | 289.39 | 0.7390 | -687.0 | -478.8 | |
| 0.00 | 0.81 | 0.00 | 0.58 | 16.60 | 59.60 | 46.47 | 286.27 | 0.7261 | 490.0 | 378.8 | |
| 1.80 | 97.54 | 1.30 | 69.98 | 18.29 | 59.88 | 46.76 | 288.53 | 0.7318 | -513.0 | 198.8 | |
| 2.16 | -21.00 | 1.53 | -21.00 | 17.31 | 58.91 | 45.78 | 287.36 | 0.7192 | 544.5 | 999999 | |
| 1.44 | -21.00 | 1.02 | -21.00 | 16.64 | 58.70 | 45.57 | 286.46 | 0.7158 | -385.7 | 999999 | |
| 0.00 | 2.69 | 0.00 | 1.97 | 20.48 | 59.96 | 46.83 | 291.49 | 0.7365 | -201.0 | -209.0 | |
| 0.00 | 0.36 | 0.00 | 0.25 | 14.81 | 58.04 | 44.91 | 283.98 | 0.7057 | 521.0 | 515.5 | |
| 0.00 | 1.08 | 0.00 | 0.75 | 15.23 | 58.11 | 44.98 | 284.57 | 0.7070 | 463.0 | 342.2 | |
| 0.00 | 0.99 | 0.00 | 0.70 | 17.85 | 58.81 | 45.68 | 288.12 | 0.7189 | 547.0 | 352.6 | |
| 0.00 | 1.17 | 0.00 | 0.85 | 20.72 | 59.77 | 46.64 | 291.85 | 0.7350 | -537.0 | -507.7 | |
| 3.14 | 17.96 | 2.28 | 13.04 | 20.46 | 59.57 | 46.44 | 291.53 | 0.7322 | -704.5 | -14.9 | |
| 0.00 | 8.89 | 0.00 | 6.39 | 19.66 | 59.26 | 46.14 | 290.52 | 0.7272 | 155.0 | 233.9 | |
| 8.80 | 39.25 | 6.19 | 27.58 | 17.52 | 58.25 | 45.12 | 287.76 | 0.7119 | 812.0 | 428.1 | |
| 1.53 | -31.00 | 1.08 | -31.00 | 17.92 | 58.37 | 45.25 | 288.29 | 0.7140 | 396.0 | 999999 | |
| 0.00 | 2.07 | 0.00 | 1.49 | 20.33 | 59.19 | 46.06 | 291.44 | 0.7278 | -328.0 | -331.6 | |
| 0.00 | 4.58 | 0.00 | 3.26 | 19.15 | 58.66 | 45.53 | 289.94 | 0.7195 | 589.0 | 569.4 | |
| 3.41 | 3.86 | 2.41 | 2.73 | 18.54 | 58.36 | 45.23 | 289.17 | 0.7149 | 689.9 | 427.8 | |
| 5.39 | -31.00 | 3.78 | -31.00 | 17.79 | 58.02 | 44.89 | 288.18 | 0.7096 | 906.3 | 999999 | |
| 1.17 | -31.00 | 0.82 | -31.00 | 18.10 | 58.07 | 44.95 | 288.60 | 0.7108 | 694.8 | 999999 | |
| 0.00 | 3.32 | 0.00 | 2.35 | 19.68 | 58.34 | 45.22 | 290.74 | 0.7169 | 570.0 | 439.5 | |
| 0.00 | 1.98 | 0.00 | 1.39 | 19.54 | 58.07 | 44.94 | 290.61 | 0.7135 | 713.0 | 585.1 | |
| 6.74 | 29.82 | 4.78 | 21.24 | 20.60 | 58.23 | 45.10 | 292.04 | 0.7176 | 695.4 | -101.0 | |
| 0.00 | 1.53 | 0.00 | 1.08 | 20.11 | 58.04 | 44.92 | 291.40 | 0.7145 | 589.0 | 458.6 | |
| 1.98 | 3.23 | 1.33 | 2.18 | 14.15 | 55.96 | 42.83 | 283.28 | 0.6796 | 777.0 | 679.2 | |
| 0.00 | 1.08 | 0.00 | 0.75 | 20.17 | 57.29 | 44.17 | 291.67 | 0.7061 | 545.0 | 465.1 | |
| 0.00 | 1.08 | 0.00 | 0.76 | 21.26 | 57.56 | 44.43 | 293.11 | 0.7117 | 458.0 | 419.8 | |
| 0.00 | 1.08 | 0.00 | 0.72 | 15.58 | 55.75 | 42.63 | 285.42 | 0.6790 | 599.0 | 394.2 | |
| 0.00 | 2.25 | 0.00 | 1.47 | 13.34 | 54.10 | 40.97 | 282.30 | 0.6553 | 731.0 | 553.6 | |
| 0.00 | 1.17 | 0.00 | 0.80 | 20.83 | 55.87 | 42.74 | 292.97 | 0.6913 | 648.0 | 557.8 | |
| 0.00 | 1.71 | 0.00 | 1.17 | 22.09 | 55.53 | 42.40 | 294.86 | 0.6910 | 702.0 | 632.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
