SDO HMI 2011-08-25 12:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.07 | 13.21 | 1.62 | 10.33 | -20.12 | 55.48 | 43.46 | 236.62 | 0.7754 | 149.5 | 191.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-25 12:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.45 | 0.00 | 0.37 | -19.17 | 59.35 | 47.33 | 239.80 | 0.8058 | 421.0 | 389.2 | |
| 0.00 | 1.26 | 0.00 | 0.98 | -14.89 | 57.82 | 45.79 | 244.03 | 0.7728 | 578.0 | 487.9 | |
| 0.00 | 2.69 | 0.00 | 2.21 | -19.60 | 58.52 | 46.50 | 238.90 | 0.8002 | 413.0 | 353.7 | |
| 2.07 | 4.49 | 1.62 | 3.51 | -20.97 | 55.10 | 43.07 | 235.48 | 0.7762 | 654.7 | 591.0 | |
| 0.00 | 1.08 | 0.00 | 0.88 | -23.90 | 55.62 | 43.59 | 232.53 | 0.7964 | 646.0 | 488.0 | |
| 0.00 | 0.72 | 0.00 | 0.54 | -20.83 | 52.26 | 40.23 | 233.91 | 0.7494 | -586.0 | -541.1 | |
| 0.00 | 1.44 | 0.00 | 1.08 | -21.14 | 52.32 | 40.29 | 233.59 | 0.7518 | -617.0 | -537.2 | |
| 0.00 | 1.08 | 0.00 | 0.76 | -18.63 | 50.16 | 38.13 | 235.09 | 0.7158 | -627.0 | -548.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
