SDO HMI 2011-08-26 21:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.42 | 0.00 | 4.05 | -20.09 | 54.35 | 60.51 | 244.04 | 0.9107 | -64.0 | -20.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-26 21:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.08 | 0.00 | 1.36 | -20.06 | 56.07 | 62.23 | 244.62 | 0.9216 | 339.0 | 256.4 | |
| 0.00 | 0.90 | 0.00 | 1.06 | -19.34 | 54.44 | 60.60 | 244.86 | 0.9098 | -204.0 | -125.6 | |
| 0.00 | 0.99 | 0.00 | 1.12 | -20.47 | 52.88 | 59.05 | 243.17 | 0.9022 | -221.0 | -177.1 | |
| 0.00 | 0.45 | 0.00 | 0.51 | -20.89 | 52.77 | 58.94 | 242.68 | 0.9025 | -170.0 | -192.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
