SDO HMI 2011-08-26 22:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.64 | 70.28 | 14.78 | 38.90 | 17.39 | 328.35 | -24.93 | 64.58 | 0.4476 | 16.7 | 56.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-26 22:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.44 | 0.00 | 0.78 | 22.62 | 334.04 | -19.24 | 47.96 | 0.4113 | 880.0 | 699.1 | |
| 0.00 | 1.35 | 0.00 | 0.72 | 15.76 | 332.66 | -20.63 | 64.95 | 0.3758 | -805.0 | -580.9 | |
| 0.00 | 2.96 | 0.00 | 1.60 | 18.40 | 331.70 | -21.59 | 59.65 | 0.4063 | -752.0 | -674.2 | |
| 0.00 | 1.26 | 0.00 | 0.68 | 18.06 | 331.61 | -21.68 | 60.51 | 0.4052 | -1026.0 | -840.6 | |
| 0.00 | 2.42 | 0.00 | 1.31 | 18.11 | 331.43 | -21.86 | 60.56 | 0.4080 | -865.0 | -728.9 | |
| 0.00 | 1.26 | 0.00 | 0.68 | 18.48 | 331.31 | -21.98 | 59.86 | 0.4121 | -730.0 | -617.5 | |
| 0.00 | 1.17 | 0.00 | 0.63 | 18.04 | 331.26 | -22.02 | 60.88 | 0.4098 | -714.0 | -611.8 | |
| 0.00 | 2.33 | 0.00 | 1.27 | 18.11 | 330.81 | -22.48 | 61.15 | 0.4166 | -629.0 | -621.8 | |
| 0.00 | 1.44 | 0.00 | 0.78 | 18.28 | 330.47 | -22.81 | 61.08 | 0.4224 | -689.0 | -552.6 | |
| 0.00 | 1.26 | 0.00 | 0.70 | 19.21 | 329.04 | -24.24 | 60.39 | 0.4478 | -791.0 | -685.2 | |
| 12.11 | 16.06 | 6.72 | 8.91 | 18.31 | 328.37 | -24.91 | 62.80 | 0.4515 | -946.7 | -692.0 | |
| 0.00 | 1.08 | 0.00 | 0.60 | 18.50 | 327.92 | -25.36 | 62.75 | 0.4588 | -833.0 | -584.1 | |
| 12.11 | 28.43 | 6.71 | 15.77 | 16.42 | 327.77 | -25.51 | 67.18 | 0.4500 | 1050.7 | 763.1 | |
| 0.63 | -13.00 | 0.35 | -13.00 | 16.08 | 327.75 | -25.53 | 67.92 | 0.4488 | 915.9 | 999999 | |
| 1.79 | -13.00 | 1.00 | -13.00 | 16.24 | 327.31 | -25.98 | 67.85 | 0.4559 | 927.5 | 999999 | |
| 0.00 | 0.90 | 0.00 | 0.50 | 16.35 | 327.01 | -26.27 | 67.81 | 0.4606 | 571.0 | 405.9 | |
| 0.00 | 0.99 | 0.00 | 0.55 | 16.53 | 326.24 | -27.04 | 67.90 | 0.4723 | 683.0 | 572.4 | |
| 0.00 | 0.90 | 0.00 | 0.50 | 14.53 | 325.79 | -27.50 | 72.24 | 0.4712 | 827.0 | 666.0 | |
| 0.00 | 1.17 | 0.00 | 0.66 | 15.11 | 325.71 | -27.58 | 71.08 | 0.4744 | 656.0 | 564.7 | |
| 0.00 | 1.70 | 0.00 | 1.00 | 21.90 | 323.73 | -29.55 | 59.40 | 0.5337 | 682.0 | 474.6 | |
| 0.00 | 1.44 | 0.00 | 0.83 | 13.84 | 322.33 | -30.95 | 74.90 | 0.5192 | 653.0 | 488.2 | |
| 0.00 | 0.72 | 0.00 | 0.43 | 16.59 | 319.63 | -33.66 | 70.80 | 0.5646 | 595.0 | 531.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
