SDO HMI 2011-08-28 03:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34.98 | 201.12 | 24.65 | 142.43 | 13.37 | 291.41 | -45.92 | 78.23 | 0.7162 | -553.9 | -213.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-28 03:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.82 | 183.81 | 18.85 | 129.62 | 13.42 | 291.81 | -45.52 | 78.13 | 0.7115 | -993.6 | -289.0 | |
| 2.42 | -1.00 | 1.72 | -1.00 | 13.49 | 291.21 | -46.12 | 78.07 | 0.7187 | -515.2 | 999999 | |
| 5.74 | -1.00 | 4.08 | -1.00 | 13.21 | 291.10 | -46.23 | 78.48 | 0.7198 | -564.9 | 999999 | |
| 0.00 | 2.06 | 0.00 | 1.47 | 12.60 | 291.15 | -46.17 | 79.33 | 0.7188 | -512.0 | -428.0 | |
| 0.00 | 1.35 | 0.00 | 0.98 | 12.15 | 289.89 | -47.43 | 80.01 | 0.7334 | 670.0 | 599.0 | |
| 0.00 | 3.14 | 0.00 | 2.29 | 12.24 | 289.59 | -47.73 | 79.89 | 0.7369 | 667.0 | 548.6 | |
| 0.00 | 0.63 | 0.00 | 0.46 | 13.80 | 289.15 | -48.18 | 77.80 | 0.7427 | 558.0 | 467.0 | |
| 0.00 | 3.23 | 0.00 | 2.40 | 13.42 | 288.64 | -48.69 | 78.35 | 0.7483 | 647.0 | 548.1 | |
| 0.00 | 2.60 | 0.00 | 1.94 | 13.66 | 288.57 | -48.75 | 78.03 | 0.7492 | 635.0 | 402.4 | |
| 0.00 | 2.15 | 0.00 | 1.62 | 13.38 | 287.93 | -49.40 | 78.43 | 0.7562 | 599.0 | 470.0 | |
| 0.00 | 2.15 | 0.00 | 1.65 | 14.06 | 287.20 | -50.12 | 77.58 | 0.7646 | 573.0 | 535.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
