SDO HMI 2011-08-28 05:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 10.61 | 0.00 | 5.76 | 18.33 | 358.21 | 21.98 | 300.33 | 0.4124 | -402.2 | -355.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-28 05:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.35 | 0.00 | 0.75 | 17.98 | 2.08 | 25.85 | 295.77 | 0.4625 | -661.0 | -579.6 | |
| 0.00 | 0.72 | 0.00 | 0.40 | 18.43 | 1.80 | 25.57 | 296.89 | 0.4610 | -802.0 | -655.2 | |
| 0.00 | 1.17 | 0.00 | 0.65 | 19.83 | 1.04 | 24.81 | 300.33 | 0.4591 | -784.0 | -627.4 | |
| 0.00 | 0.72 | 0.00 | 0.40 | 17.69 | 0.53 | 24.30 | 296.32 | 0.4392 | -865.0 | -754.4 | |
| 0.00 | 1.44 | 0.00 | 0.79 | 19.02 | 359.29 | 23.06 | 300.20 | 0.4303 | -864.0 | -679.7 | |
| 0.00 | 2.60 | 0.00 | 1.40 | 16.79 | 357.79 | 21.56 | 296.63 | 0.3952 | -748.0 | -592.1 | |
| 0.00 | 1.26 | 0.00 | 0.67 | 18.08 | 355.81 | 19.58 | 301.74 | 0.3761 | 642.0 | 490.6 | |
| 0.00 | 1.35 | 0.00 | 0.70 | 20.14 | 349.99 | 13.76 | 315.69 | 0.3211 | 864.0 | 559.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
