SDO HMI 2011-08-28 05:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 25.75 | 147.87 | 15.91 | 91.43 | 17.66 | 300.09 | -36.14 | 69.89 | 0.6007 | -872.1 | -379.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-28 05:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.26 | 0.00 | 0.75 | 13.46 | 301.81 | -34.42 | 76.54 | 0.5675 | -674.0 | -572.1 | |
| 25.75 | 140.77 | 15.91 | 86.95 | 17.72 | 300.19 | -36.04 | 69.76 | 0.5995 | -1151.4 | -397.3 | |
| 0.00 | 1.26 | 0.00 | 0.78 | 17.73 | 299.44 | -36.79 | 69.99 | 0.6094 | 91.0 | 3.8 | |
| 0.00 | 2.60 | 0.00 | 1.65 | 15.98 | 297.88 | -38.35 | 73.23 | 0.6252 | -685.0 | -454.3 | |
| 0.00 | 0.63 | 0.00 | 0.41 | 18.37 | 295.46 | -40.77 | 70.16 | 0.6612 | 686.0 | 627.1 | |
| 0.00 | 1.35 | 0.00 | 0.89 | 18.26 | 295.32 | -40.91 | 70.35 | 0.6627 | 665.0 | 581.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
