SDO HMI 2011-08-28 05:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.53 | 43.96 | 4.19 | 131.38 | -20.43 | 259.04 | -77.20 | 112.16 | 0.9871 | -342.3 | 6.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-28 05:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.53 | 29.79 | 4.19 | 78.90 | -20.86 | 260.33 | -75.90 | 112.83 | 0.9842 | -284.3 | 227.4 | |
| 0.00 | 2.33 | 0.00 | 6.83 | -20.64 | 259.41 | -76.82 | 112.44 | 0.9865 | -313.0 | -241.3 | |
| 0.00 | 1.26 | 0.00 | 4.80 | -20.75 | 256.98 | -79.25 | 112.11 | 0.9922 | -331.0 | -316.6 | |
| 0.00 | 1.70 | 0.00 | 5.52 | -19.48 | 258.17 | -78.06 | 111.06 | 0.9890 | -511.0 | -387.1 | |
| 0.00 | 3.32 | 0.00 | 13.89 | -19.90 | 256.17 | -80.06 | 111.12 | 0.9934 | -280.0 | -249.8 | |
| 0.00 | 5.56 | 0.00 | 21.44 | -19.27 | 256.69 | -79.55 | 110.59 | 0.9922 | -520.0 | -342.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
