SDO HMI 2011-08-29 07:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 23.22 | 0.00 | 12.97 | 7.54 | 349.44 | 27.52 | 272.62 | 0.4598 | -336.0 | -452.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-29 07:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.70 | 0.00 | 0.97 | 7.28 | 351.73 | 29.80 | 272.19 | 0.4953 | -766.0 | -682.6 | |
| 0.00 | 8.25 | 0.00 | 4.70 | 7.68 | 351.69 | 29.76 | 273.00 | 0.4946 | -783.0 | -716.7 | |
| 0.00 | 1.35 | 0.00 | 0.77 | 7.38 | 351.59 | 29.67 | 272.39 | 0.4933 | -845.0 | -669.5 | |
| 0.00 | 0.99 | 0.00 | 0.56 | 8.30 | 351.52 | 29.60 | 274.25 | 0.4921 | -678.0 | -510.8 | |
| 0.00 | 2.69 | 0.00 | 1.52 | 8.38 | 351.18 | 29.25 | 274.42 | 0.4869 | -843.0 | -716.6 | |
| 0.00 | 1.61 | 0.00 | 0.90 | 5.53 | 349.05 | 27.13 | 268.18 | 0.4559 | -782.0 | -638.2 | |
| 0.00 | 1.52 | 0.00 | 0.83 | 7.39 | 347.25 | 25.32 | 272.19 | 0.4263 | -725.0 | -521.8 | |
| 0.00 | 1.08 | 0.00 | 0.58 | 7.83 | 345.06 | 23.14 | 273.24 | 0.3916 | -807.0 | -697.7 | |
| 0.00 | 1.61 | 0.00 | 0.86 | 7.46 | 343.29 | 21.37 | 272.24 | 0.3631 | 887.0 | 729.7 | |
| 0.00 | 0.99 | 0.00 | 0.52 | 7.70 | 343.24 | 21.31 | 272.92 | 0.3622 | 873.0 | 652.5 | |
| 0.00 | 1.43 | 0.00 | 0.76 | 7.26 | 342.89 | 20.96 | 271.68 | 0.3566 | 773.0 | 659.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
