SDO HMI 2011-08-30 05:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.89 | 176.41 | 13.78 | 90.37 | 18.14 | 299.77 | -10.04 | 40.76 | 0.2550 | -1217.4 | -441.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-30 05:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 25.28 | 171.65 | 12.95 | 87.91 | 18.13 | 299.81 | -10.00 | 40.66 | 0.2544 | -1322.9 | -436.3 | |
| 1.61 | -1.00 | 0.83 | -1.00 | 17.79 | 299.70 | -10.11 | 41.90 | 0.2514 | -992.1 | 999999 | |
| 0.00 | 2.78 | 0.00 | 1.44 | 20.45 | 299.53 | -10.28 | 35.80 | 0.2870 | -875.0 | -653.6 | |
| 0.00 | 0.81 | 0.00 | 0.42 | 17.97 | 296.93 | -12.88 | 48.06 | 0.2864 | -860.0 | -616.6 | |
| 0.00 | 1.17 | 0.00 | 0.60 | 17.02 | 296.99 | -12.81 | 50.60 | 0.2757 | -737.0 | -491.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
