SDO HMI 2011-08-30 12:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.30 | 269.10 | 18.15 | 138.46 | 13.91 | 291.64 | -14.33 | 63.17 | 0.2705 | -591.0 | -350.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-30 12:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.34 | 0.00 | 0.69 | 18.31 | 293.91 | -12.06 | 45.29 | 0.2802 | 937.0 | 696.8 | |
| 0.00 | 1.25 | 0.00 | 0.65 | 18.27 | 293.26 | -12.70 | 46.86 | 0.2875 | 268.0 | 334.6 | |
| 0.00 | 2.24 | 0.00 | 1.14 | 9.42 | 293.43 | -12.53 | 78.76 | 0.2193 | -618.0 | -562.8 | |
| 35.30 | 251.82 | 18.15 | 129.48 | 13.87 | 291.75 | -14.22 | 63.14 | 0.2684 | -1265.7 | -412.4 | |
| 0.00 | 1.34 | 0.00 | 0.70 | 16.31 | 290.64 | -15.33 | 57.20 | 0.3032 | 901.0 | 767.8 | |
| 0.00 | 0.90 | 0.00 | 0.46 | 15.63 | 290.53 | -15.44 | 59.35 | 0.2993 | -627.0 | -426.1 | |
| 0.00 | 2.69 | 0.00 | 1.40 | 13.64 | 289.47 | -16.50 | 66.83 | 0.3015 | 890.0 | 718.5 | |
| 0.00 | 1.52 | 0.00 | 0.79 | 13.95 | 288.73 | -17.24 | 66.69 | 0.3145 | 857.0 | 717.3 | |
| 0.00 | 1.88 | 0.00 | 0.98 | 14.16 | 288.65 | -17.32 | 66.15 | 0.3169 | 697.0 | 535.9 | |
| 0.00 | 1.16 | 0.00 | 0.61 | 14.30 | 288.15 | -17.82 | 66.29 | 0.3253 | 840.0 | 674.8 | |
| 0.00 | 1.88 | 0.00 | 0.99 | 15.17 | 286.92 | -19.05 | 65.12 | 0.3488 | 770.0 | 558.0 | |
| 0.00 | 1.08 | 0.00 | 0.57 | 15.35 | 286.87 | -19.10 | 64.68 | 0.3506 | 830.0 | 594.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
