SDO HMI 2011-08-30 13:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29.38 | 168.48 | 14.90 | 85.44 | 18.12 | 299.76 | -5.66 | 26.14 | 0.2137 | -1150.1 | -441.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-30 13:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.33 | 0.00 | 1.16 | 14.07 | 301.91 | -3.51 | 26.20 | 0.1351 | -992.0 | -769.2 | |
| 0.00 | 1.25 | 0.00 | 0.63 | 14.43 | 301.52 | -3.89 | 27.35 | 0.1437 | -839.0 | -721.7 | |
| 29.11 | 161.32 | 14.76 | 81.83 | 18.21 | 299.79 | -5.63 | 25.83 | 0.2148 | -1239.2 | -426.2 | |
| 0.27 | -3.00 | 0.14 | -3.00 | 18.24 | 299.37 | -6.05 | 27.40 | 0.2184 | -910.0 | 999999 | |
| 0.00 | 1.79 | 0.00 | 0.91 | 17.38 | 297.64 | -7.77 | 35.83 | 0.2215 | -832.0 | -606.1 | |
| 0.00 | 1.79 | 0.00 | 0.91 | 18.30 | 297.25 | -8.17 | 34.73 | 0.2379 | -897.0 | -779.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
