SDO HMI 2011-08-30 14:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.35 | 34.02 | 11.38 | 28.72 | 18.48 | 359.26 | 54.39 | 287.69 | 0.8114 | -527.4 | -218.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-30 14:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.72 | 22.75 | 10.87 | 19.45 | 18.51 | 359.83 | 54.96 | 287.67 | 0.8170 | -742.3 | -448.8 | |
| 0.00 | 1.07 | 0.00 | 0.91 | 19.18 | 359.15 | 54.29 | 288.55 | 0.8111 | -638.0 | -472.7 | |
| 0.00 | 1.70 | 0.00 | 1.39 | 17.73 | 357.94 | 53.08 | 286.87 | 0.7980 | 472.0 | 342.1 | |
| 0.00 | 2.15 | 0.00 | 1.79 | 19.27 | 358.53 | 53.67 | 288.73 | 0.8052 | -726.0 | -648.1 | |
| 0.00 | 1.79 | 0.00 | 1.48 | 19.29 | 358.33 | 53.46 | 288.78 | 0.8032 | -679.0 | -488.2 | |
| 0.63 | 3.31 | 0.51 | 2.69 | 17.67 | 357.55 | 52.69 | 286.84 | 0.7940 | 695.0 | 584.3 | |
| 0.00 | 1.25 | 0.00 | 1.01 | 17.94 | 357.40 | 52.53 | 287.19 | 0.7927 | 647.0 | 623.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
