SDO HMI 2011-08-31 00:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.36 | 75.12 | 18.39 | 39.12 | 24.98 | 298.97 | -0.37 | 0.98 | 0.3084 | -168.8 | 119.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-08-31 00:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.60 | 23.73 | 7.58 | 12.33 | 24.56 | 301.23 | 1.89 | 354.27 | 0.3016 | -1005.6 | -664.6 | |
| 3.04 | -1.00 | 1.58 | -1.00 | 24.78 | 301.00 | 1.66 | 355.04 | 0.3049 | -802.8 | 999999 | |
| 0.00 | 1.88 | 0.00 | 0.98 | 25.20 | 300.07 | 0.73 | 357.87 | 0.3109 | -615.0 | -457.4 | |
| 0.00 | 1.16 | 0.00 | 0.61 | 24.85 | 300.06 | 0.72 | 357.83 | 0.3050 | -813.0 | -552.3 | |
| 3.13 | 4.66 | 1.63 | 2.43 | 25.17 | 299.60 | 0.26 | 359.24 | 0.3102 | -931.2 | -799.3 | |
| 0.45 | 1.97 | 0.23 | 1.03 | 25.83 | 299.16 | -0.18 | 0.50 | 0.3213 | 709.4 | 529.6 | |
| 0.00 | 1.25 | 0.00 | 0.65 | 24.21 | 299.03 | -0.31 | 0.96 | 0.2943 | -909.0 | -721.7 | |
| 5.73 | 6.90 | 2.97 | 3.57 | 24.12 | 298.77 | -0.57 | 1.79 | 0.2928 | -975.9 | -721.2 | |
| 0.00 | 2.51 | 0.00 | 1.30 | 24.18 | 298.30 | -1.04 | 3.23 | 0.2942 | -682.0 | -621.0 | |
| 0.00 | 3.85 | 0.00 | 2.00 | 25.00 | 298.20 | -1.14 | 3.38 | 0.3080 | 983.0 | 703.3 | |
| 0.00 | 0.99 | 0.00 | 0.51 | 24.66 | 298.03 | -1.31 | 3.95 | 0.3024 | 716.0 | 520.0 | |
| 0.00 | 1.16 | 0.00 | 0.60 | 24.65 | 297.83 | -1.51 | 4.55 | 0.3026 | 621.0 | 473.2 | |
| 1.88 | 7.34 | 0.98 | 3.84 | 25.70 | 297.69 | -1.65 | 4.68 | 0.3202 | 955.2 | 531.5 | |
| 1.25 | -13.00 | 0.66 | -13.00 | 25.86 | 297.65 | -1.69 | 4.74 | 0.3229 | 837.2 | 999999 | |
| 0.00 | 0.54 | 0.00 | 0.28 | 26.15 | 297.48 | -1.86 | 5.13 | 0.3279 | 756.0 | 629.3 | |
| 0.00 | 1.25 | 0.00 | 0.65 | 24.84 | 297.36 | -1.98 | 5.89 | 0.3064 | 785.0 | 622.9 | |
| 0.00 | 1.16 | 0.00 | 0.61 | 25.64 | 296.91 | -2.43 | 6.87 | 0.3204 | 692.0 | 548.8 | |
| 2.24 | 8.87 | 1.17 | 4.63 | 25.41 | 296.85 | -2.49 | 7.14 | 0.3168 | 999.0 | 766.4 | |
| 1.61 | -18.00 | 0.84 | -18.00 | 25.54 | 296.68 | -2.66 | 7.57 | 0.3193 | 906.2 | 999999 | |
| 0.00 | 1.43 | 0.00 | 0.75 | 25.19 | 296.62 | -2.72 | 7.90 | 0.3136 | 941.0 | 772.0 | |
| 0.00 | 1.16 | 0.00 | 0.61 | 25.60 | 296.34 | -3.00 | 8.48 | 0.3211 | 740.0 | 559.9 | |
| 0.00 | 1.34 | 0.00 | 0.70 | 25.44 | 296.08 | -3.26 | 9.30 | 0.3191 | 796.0 | 646.0 | |
| 1.43 | 1.97 | 0.75 | 1.04 | 26.30 | 295.72 | -3.62 | 9.80 | 0.3341 | -616.9 | -523.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
