SDO HMI 2011-09-02 09:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 84.75 | 378.38 | 51.27 | 230.58 | 24.36 | 300.29 | 32.31 | 303.11 | 0.5823 | -72.0 | -41.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-09-02 09:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 28.01 | 191.61 | 17.61 | 120.42 | 23.15 | 303.89 | 35.91 | 298.82 | 0.6177 | -1097.2 | -317.6 | |
| 5.01 | -1.00 | 3.14 | -1.00 | 23.15 | 303.49 | 35.50 | 299.01 | 0.6128 | -1184.6 | 999999 | |
| 1.34 | -1.00 | 0.84 | -1.00 | 23.26 | 303.24 | 35.25 | 299.31 | 0.6103 | -1067.0 | 999999 | |
| 0.00 | 0.63 | 0.00 | 0.40 | 24.76 | 303.72 | 35.73 | 301.35 | 0.6232 | -570.0 | -454.4 | |
| 0.00 | 1.07 | 0.00 | 0.67 | 23.53 | 302.96 | 34.97 | 299.88 | 0.6083 | -963.0 | -809.2 | |
| 1.61 | 13.42 | 1.01 | 8.36 | 24.10 | 303.01 | 35.03 | 300.73 | 0.6117 | -699.2 | -743.9 | |
| 0.00 | 1.34 | 0.00 | 0.83 | 23.10 | 302.71 | 34.72 | 299.35 | 0.6032 | -812.0 | -731.7 | |
| 1.79 | 2.42 | 1.11 | 1.49 | 24.11 | 302.01 | 34.02 | 301.29 | 0.5998 | -715.6 | -710.0 | |
| 0.00 | 1.70 | 0.00 | 1.04 | 24.35 | 301.24 | 33.25 | 302.11 | 0.5920 | -834.0 | -719.6 | |
| 0.00 | 0.63 | 0.00 | 0.38 | 24.43 | 300.99 | 33.00 | 302.39 | 0.5894 | -406.0 | -281.7 | |
| 0.00 | 1.61 | 0.00 | 0.98 | 24.75 | 300.49 | 32.50 | 303.20 | 0.5853 | -832.0 | -681.9 | |
| 1.43 | 2.42 | 0.87 | 1.47 | 24.99 | 300.24 | 32.25 | 303.74 | 0.5839 | -755.3 | -658.5 | |
| 0.00 | 1.43 | 0.00 | 0.87 | 25.60 | 300.19 | 32.20 | 304.73 | 0.5869 | -731.0 | -559.7 | |
| 3.04 | 3.67 | 1.85 | 2.23 | 25.01 | 299.97 | 31.98 | 303.94 | 0.5808 | -871.5 | -694.9 | |
| 0.00 | 0.63 | 0.00 | 0.38 | 25.27 | 299.89 | 31.90 | 304.40 | 0.5814 | -670.0 | -576.9 | |
| 0.00 | 1.16 | 0.00 | 0.71 | 25.68 | 300.01 | 32.02 | 304.96 | 0.5853 | -683.0 | -567.5 | |
| 0.00 | 0.89 | 0.00 | 0.54 | 25.05 | 298.69 | 30.70 | 304.89 | 0.5660 | 562.0 | 377.8 | |
| 0.00 | 0.89 | 0.00 | 0.53 | 24.51 | 298.23 | 30.24 | 304.33 | 0.5571 | 478.0 | 518.8 | |
| 1.16 | 2.15 | 0.69 | 1.28 | 24.80 | 298.04 | 30.05 | 304.95 | 0.5568 | 720.8 | 788.1 | |
| 1.97 | 2.77 | 1.16 | 1.64 | 25.13 | 296.90 | 28.91 | 306.34 | 0.5455 | 586.4 | 389.8 | |
| 0.45 | 2.24 | 0.26 | 1.32 | 25.24 | 296.66 | 28.67 | 306.70 | 0.5434 | 773.2 | 581.8 | |
| 2.51 | 3.76 | 1.47 | 2.21 | 25.32 | 296.34 | 28.35 | 307.10 | 0.5402 | 909.7 | 705.9 | |
| 0.36 | 25.15 | 0.21 | 14.74 | 25.59 | 296.07 | 28.08 | 307.76 | 0.5390 | 855.5 | 640.4 | |
| 0.45 | 1.61 | 0.26 | 0.94 | 25.34 | 295.96 | 27.98 | 307.44 | 0.5360 | 856.2 | 730.5 | |
| 3.31 | 27.12 | 1.96 | 16.04 | 26.78 | 296.19 | 28.20 | 309.55 | 0.5492 | 662.2 | 282.5 | |
| 0.89 | -25.00 | 0.53 | -25.00 | 26.60 | 295.98 | 28.00 | 309.43 | 0.5456 | 867.8 | 999999 | |
| 0.00 | 2.95 | 0.00 | 1.72 | 25.10 | 295.60 | 27.61 | 307.35 | 0.5301 | 824.0 | 627.4 | |
| 3.49 | -25.00 | 2.06 | -25.00 | 26.76 | 295.88 | 27.89 | 309.79 | 0.5456 | 938.2 | 999999 | |
| 0.00 | 1.43 | 0.00 | 0.83 | 24.39 | 295.24 | 27.25 | 306.46 | 0.5206 | 281.0 | 339.6 | |
| 2.06 | -23.00 | 1.21 | -23.00 | 25.95 | 295.47 | 27.48 | 308.84 | 0.5348 | 794.1 | 999999 | |
| 1.52 | 1.79 | 0.90 | 1.05 | 26.92 | 295.46 | 27.47 | 310.39 | 0.5421 | 751.2 | 701.7 | |
| 0.00 | 1.79 | 0.00 | 1.05 | 26.61 | 295.18 | 27.20 | 310.15 | 0.5367 | 628.0 | 566.7 | |
| 4.03 | 73.83 | 2.34 | 42.82 | 25.75 | 294.86 | 26.87 | 309.07 | 0.5263 | 901.6 | 539.5 | |
| 16.74 | -33.00 | 9.71 | -33.00 | 25.81 | 294.49 | 26.50 | 309.48 | 0.5225 | 1133.1 | 999999 | |
| 1.25 | 4.30 | 0.73 | 2.51 | 26.83 | 294.71 | 26.72 | 310.92 | 0.5331 | 679.7 | 681.1 | |
| 2.33 | -33.00 | 1.35 | -33.00 | 26.26 | 294.41 | 26.43 | 310.29 | 0.5253 | 836.3 | 999999 | |
| 0.00 | 1.97 | 0.00 | 1.13 | 25.24 | 293.72 | 25.73 | 309.25 | 0.5092 | 778.0 | 565.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
