SDO HMI 2011-09-02 13:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 85.92 | 369.82 | 53.15 | 231.62 | 24.27 | 300.60 | 34.81 | 301.46 | 0.6111 | 6.9 | -21.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-09-02 13:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.63 | 0.00 | 0.45 | 29.89 | 308.87 | 43.08 | 305.03 | 0.7255 | 421.0 | 388.0 | |
| 0.00 | 0.80 | 0.00 | 0.53 | 23.68 | 305.59 | 39.80 | 297.90 | 0.6656 | 550.0 | 444.3 | |
| 31.57 | 212.24 | 20.40 | 137.20 | 23.14 | 303.91 | 38.12 | 297.79 | 0.6440 | -1075.6 | -271.0 | |
| 0.98 | -3.00 | 0.63 | -3.00 | 23.08 | 303.39 | 37.60 | 297.93 | 0.6376 | -1110.6 | 999999 | |
| 0.00 | 1.43 | 0.00 | 0.92 | 23.39 | 303.12 | 37.33 | 298.52 | 0.6357 | -838.0 | -759.1 | |
| 1.52 | -3.00 | 0.98 | -3.00 | 23.92 | 303.25 | 37.47 | 299.25 | 0.6396 | -580.6 | 999999 | |
| 1.34 | -3.00 | 0.86 | -3.00 | 23.90 | 303.04 | 37.25 | 299.32 | 0.6370 | -921.2 | 999999 | |
| 1.25 | -3.00 | 0.80 | -3.00 | 24.15 | 302.75 | 36.96 | 299.83 | 0.6347 | -684.2 | 999999 | |
| 1.07 | 2.24 | 0.68 | 1.42 | 24.02 | 302.29 | 36.50 | 299.86 | 0.6287 | -602.7 | -651.4 | |
| 0.00 | 1.61 | 0.00 | 1.01 | 23.55 | 301.69 | 35.90 | 299.44 | 0.6195 | -748.0 | -588.1 | |
| 0.00 | 1.79 | 0.00 | 1.13 | 24.31 | 301.32 | 35.53 | 300.79 | 0.6187 | -780.0 | -605.3 | |
| 0.00 | 0.98 | 0.00 | 0.62 | 24.68 | 300.62 | 34.83 | 301.72 | 0.6124 | -698.0 | -510.4 | |
| 1.43 | 2.68 | 0.89 | 1.67 | 24.89 | 300.36 | 34.58 | 302.19 | 0.6105 | -633.0 | -543.2 | |
| 2.06 | 3.49 | 1.28 | 2.17 | 24.97 | 300.11 | 34.32 | 302.46 | 0.6079 | -815.0 | -711.8 | |
| 0.00 | 1.43 | 0.00 | 0.88 | 25.92 | 298.91 | 33.13 | 304.62 | 0.5995 | -649.0 | -497.6 | |
| 0.00 | 2.06 | 0.00 | 1.25 | 24.87 | 297.72 | 31.93 | 303.76 | 0.5794 | 881.0 | 641.8 | |
| 0.00 | 1.16 | 0.00 | 0.70 | 25.13 | 297.13 | 31.34 | 304.57 | 0.5740 | 549.0 | 389.5 | |
| 1.97 | 4.56 | 1.18 | 2.74 | 25.15 | 296.78 | 31.00 | 304.84 | 0.5701 | 687.9 | 582.3 | |
| 0.00 | 0.80 | 0.00 | 0.48 | 25.47 | 296.40 | 30.62 | 305.61 | 0.5677 | 523.0 | 422.9 | |
| 2.77 | 15.56 | 1.66 | 9.31 | 25.38 | 296.15 | 30.36 | 305.66 | 0.5642 | 828.9 | 591.2 | |
| 0.00 | 2.33 | 0.00 | 1.39 | 25.65 | 296.03 | 30.24 | 306.17 | 0.5645 | 520.0 | 580.7 | |
| 0.00 | 1.25 | 0.00 | 0.75 | 24.96 | 295.80 | 30.01 | 305.23 | 0.5573 | 653.0 | 522.4 | |
| 0.89 | -20.00 | 0.53 | -20.00 | 25.44 | 295.77 | 29.99 | 306.02 | 0.5602 | 851.0 | 999999 | |
| 3.04 | 25.31 | 1.83 | 15.23 | 26.78 | 296.08 | 30.29 | 307.89 | 0.5727 | 581.5 | 314.9 | |
| 0.00 | 1.25 | 0.00 | 0.75 | 25.70 | 295.77 | 29.98 | 306.44 | 0.5618 | 560.0 | 506.6 | |
| 1.70 | 2.59 | 1.02 | 1.55 | 26.02 | 295.70 | 29.92 | 307.00 | 0.5633 | 546.8 | 514.4 | |
| 0.00 | 3.04 | 0.00 | 1.81 | 25.17 | 295.47 | 29.68 | 305.82 | 0.5548 | 832.0 | 670.4 | |
| 7.51 | -24.00 | 4.51 | -24.00 | 26.70 | 295.74 | 29.95 | 308.02 | 0.5684 | 857.9 | 999999 | |
| 2.68 | 16.28 | 1.60 | 9.69 | 25.66 | 295.37 | 29.58 | 306.67 | 0.5569 | 876.2 | 721.9 | |
| 3.13 | -29.00 | 1.87 | -29.00 | 25.91 | 295.36 | 29.57 | 307.09 | 0.5586 | 860.6 | 999999 | |
| 0.00 | 0.72 | 0.00 | 0.43 | 26.55 | 295.03 | 29.25 | 308.33 | 0.5593 | 683.0 | 569.6 | |
| 4.47 | 54.92 | 2.65 | 32.41 | 25.70 | 294.65 | 28.86 | 307.30 | 0.5489 | 813.1 | 552.0 | |
| 5.90 | -32.00 | 3.48 | -32.00 | 25.49 | 294.33 | 28.54 | 307.23 | 0.5437 | 1154.2 | 999999 | |
| 7.78 | -32.00 | 4.60 | -32.00 | 26.03 | 294.39 | 28.61 | 308.04 | 0.5484 | 905.9 | 999999 | |
| 1.43 | 5.19 | 0.85 | 3.09 | 26.90 | 294.55 | 28.76 | 309.27 | 0.5565 | 698.8 | 597.6 | |
| 1.43 | -32.00 | 0.85 | -32.00 | 26.52 | 294.41 | 28.62 | 308.79 | 0.5521 | 867.6 | 999999 | |
| 0.00 | 0.98 | 0.00 | 0.58 | 26.67 | 294.02 | 28.24 | 309.35 | 0.5489 | 492.0 | 437.1 | |
| 0.00 | 1.52 | 0.00 | 0.89 | 25.15 | 293.59 | 27.81 | 307.27 | 0.5327 | 630.0 | 495.9 | |
| 0.00 | 0.98 | 0.00 | 0.57 | 25.21 | 293.00 | 27.22 | 307.87 | 0.5263 | 668.0 | 581.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
