SDO HMI 2011-09-02 15:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 72.34 | 344.04 | 40.50 | 192.57 | -19.59 | 257.83 | -6.85 | 165.93 | 0.4661 | 48.0 | -25.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-09-02 15:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.25 | 0.00 | 0.70 | -20.17 | 262.13 | -2.55 | 174.81 | 0.4633 | 935.0 | 740.0 | |
| 0.00 | 1.07 | 0.00 | 0.61 | -21.23 | 261.95 | -2.73 | 174.67 | 0.4799 | 923.0 | 799.9 | |
| 0.00 | 2.59 | 0.00 | 1.48 | -22.20 | 261.93 | -2.75 | 174.83 | 0.4947 | 565.0 | 422.9 | |
| 0.00 | 1.79 | 0.00 | 1.01 | -20.99 | 261.79 | -2.89 | 174.31 | 0.4765 | 802.0 | 685.3 | |
| 0.00 | 0.98 | 0.00 | 0.55 | -21.16 | 261.56 | -3.12 | 173.90 | 0.4795 | 731.0 | 563.6 | |
| 0.00 | 1.16 | 0.00 | 0.65 | -20.79 | 260.89 | -3.79 | 172.49 | 0.4750 | 780.0 | 565.8 | |
| 0.00 | 1.52 | 0.00 | 0.85 | -20.18 | 260.23 | -4.46 | 170.98 | 0.4672 | 519.0 | 497.3 | |
| 3.76 | 5.10 | 2.10 | 2.85 | -19.85 | 259.75 | -4.93 | 169.91 | 0.4633 | 912.1 | 671.2 | |
| 0.00 | 1.61 | 0.00 | 0.90 | -20.12 | 259.61 | -5.07 | 169.75 | 0.4678 | 89.0 | 99.6 | |
| 2.59 | 5.10 | 1.49 | 2.93 | -22.92 | 259.45 | -5.23 | 170.49 | 0.5103 | -795.0 | -590.9 | |
| 9.30 | 19.13 | 5.21 | 10.74 | -20.23 | 259.26 | -5.43 | 169.08 | 0.4705 | 929.6 | 467.5 | |
| 12.70 | 255.36 | 7.09 | 142.80 | -19.72 | 258.89 | -5.80 | 168.12 | 0.4639 | 1124.2 | -36.9 | |
| 0.00 | 2.24 | 0.00 | 1.27 | -21.61 | 258.78 | -5.90 | 168.76 | 0.4926 | 683.0 | 658.0 | |
| 1.88 | 7.87 | 1.07 | 4.49 | -22.03 | 258.47 | -6.22 | 168.37 | 0.4998 | 854.5 | 732.9 | |
| 13.23 | -12.00 | 7.41 | -12.00 | -19.86 | 258.52 | -6.16 | 167.48 | 0.4672 | 916.5 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.62 | -23.11 | 258.22 | -6.46 | 168.39 | 0.5165 | 702.0 | 568.1 | |
| 0.00 | 1.07 | 0.00 | 0.62 | -23.46 | 258.17 | -6.51 | 168.45 | 0.5218 | 611.0 | 441.5 | |
| 0.00 | 0.89 | 0.00 | 0.51 | -22.31 | 258.06 | -6.62 | 167.76 | 0.5052 | 658.0 | 463.5 | |
| 0.00 | 11.36 | 0.00 | 6.28 | -18.22 | 257.66 | -7.03 | 164.82 | 0.4457 | -158.0 | -285.7 | |
| 0.00 | 1.70 | 0.00 | 0.91 | -13.91 | 257.75 | -6.94 | 161.92 | 0.3794 | -612.0 | -483.7 | |
| 0.00 | 1.61 | 0.00 | 0.89 | -17.72 | 257.39 | -7.29 | 163.95 | 0.4393 | -916.0 | -800.0 | |
| 5.45 | -12.00 | 3.05 | -12.00 | -19.41 | 257.22 | -7.46 | 164.67 | 0.4653 | -847.4 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.59 | -18.40 | 257.23 | -7.45 | 164.07 | 0.4501 | -834.0 | -665.7 | |
| 0.00 | 1.43 | 0.00 | 0.79 | -17.63 | 257.17 | -7.51 | 163.43 | 0.4388 | -874.0 | -731.1 | |
| 1.61 | -12.00 | 0.90 | -12.00 | -19.65 | 256.95 | -7.74 | 164.29 | 0.4700 | -645.3 | 999999 | |
| 0.00 | 3.84 | 0.00 | 2.14 | -18.64 | 256.93 | -7.75 | 163.62 | 0.4550 | -1006.0 | -798.3 | |
| 0.98 | -12.00 | 0.55 | -12.00 | -19.52 | 256.82 | -7.86 | 163.97 | 0.4685 | -807.8 | 999999 | |
| 0.00 | 1.25 | 0.00 | 0.69 | -17.40 | 256.83 | -7.86 | 162.56 | 0.4370 | -793.0 | -681.4 | |
| 0.00 | 1.43 | 0.00 | 0.80 | -19.72 | 256.72 | -7.97 | 163.89 | 0.4720 | -580.0 | -457.8 | |
| 5.99 | -12.00 | 3.35 | -12.00 | -19.18 | 256.71 | -7.97 | 163.53 | 0.4640 | -1034.4 | 999999 | |
| 0.00 | 0.89 | 0.00 | 0.51 | -20.41 | 256.39 | -8.29 | 163.69 | 0.4835 | -790.0 | -622.9 | |
| 3.67 | -12.00 | 2.04 | -12.00 | -18.65 | 256.41 | -8.27 | 162.60 | 0.4574 | -1061.6 | 999999 | |
| 0.00 | 1.88 | 0.00 | 1.03 | -17.44 | 256.34 | -8.34 | 161.59 | 0.4399 | -693.0 | -549.3 | |
| 11.18 | -12.00 | 6.24 | -12.00 | -18.99 | 256.24 | -8.45 | 162.48 | 0.4633 | -993.0 | 999999 | |
| 0.00 | 0.98 | 0.00 | 0.55 | -19.97 | 256.12 | -8.56 | 162.91 | 0.4783 | -629.0 | -536.3 | |
| 0.00 | 1.34 | 0.00 | 0.75 | -19.44 | 255.76 | -8.92 | 161.87 | 0.4721 | -774.0 | -650.5 | |
| 0.00 | 2.06 | 0.00 | 1.16 | -19.58 | 255.56 | -9.13 | 161.59 | 0.4751 | -578.0 | -465.6 | |
| 0.00 | 2.06 | 0.00 | 1.16 | -19.79 | 255.15 | -9.53 | 160.99 | 0.4802 | -683.0 | -561.7 | |
| 0.00 | 1.34 | 0.00 | 0.74 | -16.22 | 253.52 | -11.16 | 154.81 | 0.4385 | -648.0 | -509.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
