SDO HMI 2011-09-02 22:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 73.93 | 300.56 | 41.11 | 167.24 | -19.50 | 257.60 | -3.22 | 173.23 | 0.4549 | -98.0 | 74.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-09-02 22:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.89 | 0.00 | 0.50 | -21.33 | 262.24 | 1.43 | 182.78 | 0.4804 | 867.0 | 612.7 | |
| 0.00 | 0.80 | 0.00 | 0.45 | -21.50 | 262.21 | 1.40 | 182.70 | 0.4831 | 742.0 | 548.3 | |
| 0.00 | 6.17 | 0.00 | 3.47 | -21.12 | 261.95 | 1.13 | 182.22 | 0.4770 | 936.0 | 693.0 | |
| 0.00 | 1.34 | 0.00 | 0.75 | -20.16 | 260.10 | -0.71 | 178.55 | 0.4620 | 747.0 | 538.4 | |
| 0.98 | 3.40 | 0.55 | 1.89 | -19.86 | 259.69 | -1.13 | 177.67 | 0.4575 | 900.9 | 813.4 | |
| 1.52 | 2.86 | 0.87 | 1.64 | -22.89 | 259.46 | -1.35 | 177.53 | 0.5042 | -810.4 | -847.3 | |
| 8.40 | 15.56 | 4.69 | 8.69 | -20.13 | 259.23 | -1.58 | 176.77 | 0.4620 | 959.8 | 564.7 | |
| 13.32 | 220.83 | 7.40 | 122.74 | -19.66 | 258.82 | -1.99 | 175.85 | 0.4551 | 1177.7 | 157.9 | |
| 1.79 | 3.84 | 1.02 | 2.18 | -21.99 | 258.76 | -2.06 | 176.10 | 0.4911 | 818.6 | 592.7 | |
| 0.54 | -8.00 | 0.30 | -8.00 | -19.93 | 258.75 | -2.06 | 175.76 | 0.4594 | 989.8 | 999999 | |
| 0.00 | 1.70 | 0.00 | 0.96 | -21.61 | 258.60 | -2.22 | 175.74 | 0.4854 | 881.0 | 718.0 | |
| 3.31 | -8.00 | 1.84 | -8.00 | -19.93 | 258.59 | -2.22 | 175.43 | 0.4596 | 1016.5 | 999999 | |
| 1.16 | -8.00 | 0.64 | -8.00 | -19.39 | 258.60 | -2.22 | 175.35 | 0.4511 | 1015.2 | 999999 | |
| 3.93 | -8.00 | 2.19 | -8.00 | -19.59 | 258.27 | -2.54 | 174.71 | 0.4548 | 883.8 | 999999 | |
| 0.00 | 0.36 | 0.00 | 0.21 | -23.14 | 258.21 | -2.60 | 175.28 | 0.5092 | 606.0 | 587.5 | |
| 0.00 | 0.98 | 0.00 | 0.53 | -15.26 | 258.11 | -2.70 | 173.22 | 0.3866 | -795.0 | -594.5 | |
| 0.00 | 2.15 | 0.00 | 1.24 | -23.46 | 257.91 | -2.91 | 174.79 | 0.5143 | 567.0 | 524.3 | |
| 0.00 | 1.61 | 0.00 | 0.88 | -18.11 | 257.91 | -2.90 | 173.59 | 0.4322 | -646.0 | -489.2 | |
| 0.00 | 1.25 | 0.00 | 0.69 | -18.21 | 257.56 | -3.25 | 172.85 | 0.4345 | -786.0 | -598.4 | |
| 0.00 | 1.16 | 0.00 | 0.64 | -18.18 | 257.34 | -3.47 | 172.35 | 0.4344 | -884.0 | -744.0 | |
| 0.00 | 1.25 | 0.00 | 0.69 | -17.85 | 257.35 | -3.47 | 172.26 | 0.4292 | -840.0 | -690.5 | |
| 0.00 | 1.07 | 0.00 | 0.61 | -22.52 | 257.17 | -3.64 | 173.26 | 0.5014 | 726.0 | 594.7 | |
| 1.61 | -8.00 | 0.89 | -8.00 | -19.46 | 257.25 | -3.57 | 172.56 | 0.4545 | 103.6 | 999999 | |
| 7.60 | -8.00 | 4.22 | -8.00 | -19.33 | 257.22 | -3.59 | 172.46 | 0.4525 | -599.6 | 999999 | |
| 1.25 | 10.91 | 0.69 | 6.02 | -18.82 | 257.20 | -3.62 | 172.26 | 0.4447 | -680.4 | -627.2 | |
| 0.00 | 1.61 | 0.00 | 0.88 | -17.52 | 257.10 | -3.72 | 171.60 | 0.4245 | -913.0 | -724.7 | |
| 0.00 | 2.06 | 0.00 | 1.13 | -18.22 | 257.08 | -3.73 | 171.81 | 0.4356 | -744.0 | -492.4 | |
| 1.61 | -8.00 | 0.90 | -8.00 | -19.53 | 256.89 | -3.92 | 171.85 | 0.4564 | -605.3 | 999999 | |
| 12.25 | -8.00 | 6.80 | -8.00 | -19.23 | 256.52 | -4.30 | 170.97 | 0.4526 | -943.5 | 999999 | |
| 4.29 | -8.00 | 2.37 | -8.00 | -18.66 | 256.47 | -4.35 | 170.65 | 0.4439 | -1050.2 | 999999 | |
| 0.00 | 5.45 | 0.00 | 3.06 | -20.36 | 256.39 | -4.43 | 171.11 | 0.4701 | -768.0 | -714.4 | |
| 0.00 | 2.15 | 0.00 | 1.20 | -19.81 | 256.21 | -4.60 | 170.56 | 0.4623 | -737.0 | -594.1 | |
| 10.37 | -8.00 | 5.74 | -8.00 | -18.93 | 256.20 | -4.61 | 170.20 | 0.4488 | -1078.7 | 999999 | |
| 0.00 | 1.25 | 0.00 | 0.70 | -19.41 | 255.96 | -4.85 | 169.90 | 0.4567 | -769.0 | -684.1 | |
| 0.00 | 1.52 | 0.00 | 0.84 | -18.73 | 255.86 | -4.96 | 169.40 | 0.4467 | -775.0 | -568.3 | |
| 0.00 | 1.16 | 0.00 | 0.65 | -19.58 | 255.83 | -4.98 | 169.70 | 0.4597 | -745.0 | -587.2 | |
| 0.00 | 1.70 | 0.00 | 0.94 | -19.21 | 255.84 | -4.97 | 169.57 | 0.4540 | -597.0 | -487.0 | |
| 0.00 | 1.16 | 0.00 | 0.65 | -19.62 | 255.51 | -5.31 | 169.07 | 0.4612 | -750.0 | -624.8 | |
| 0.00 | 0.98 | 0.00 | 0.55 | -19.66 | 255.09 | -5.73 | 168.24 | 0.4631 | -725.0 | -619.8 | |
| 0.00 | 0.89 | 0.00 | 0.49 | -17.17 | 255.04 | -5.77 | 166.88 | 0.4252 | -823.0 | -670.3 | |
| 0.00 | 0.80 | 0.00 | 0.44 | -17.45 | 254.59 | -6.23 | 166.05 | 0.4311 | -807.0 | -717.8 | |
| 0.00 | 1.70 | 0.00 | 0.93 | -16.47 | 253.41 | -7.40 | 162.87 | 0.4212 | -680.0 | -582.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
