SDO HMI 2011-09-03 07:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 67.46 | 263.00 | 37.42 | 146.15 | -19.53 | 257.98 | 2.10 | 184.32 | 0.4537 | 68.0 | 9.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-09-03 07:59:08 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.07 | 0.00 | 0.61 | -22.22 | 262.52 | 6.64 | 192.31 | 0.5043 | 697.0 | 526.7 | |
| 0.00 | 3.76 | 0.00 | 2.13 | -21.32 | 262.25 | 6.37 | 192.23 | 0.4901 | 926.0 | 751.5 | |
| 0.00 | 1.16 | 0.00 | 0.66 | -21.56 | 262.26 | 6.38 | 192.13 | 0.4937 | 767.0 | 598.2 | |
| 0.00 | 1.70 | 0.00 | 0.96 | -20.66 | 261.47 | 5.59 | 191.05 | 0.4777 | 751.0 | 585.3 | |
| 0.00 | 1.88 | 0.00 | 1.06 | -20.79 | 261.25 | 5.37 | 190.57 | 0.4791 | 923.0 | 704.5 | |
| 0.00 | 1.16 | 0.00 | 0.65 | -19.99 | 259.90 | 4.02 | 188.20 | 0.4635 | 696.0 | 524.5 | |
| 0.98 | 1.70 | 0.55 | 0.95 | -19.85 | 259.76 | 3.89 | 187.98 | 0.4611 | 941.9 | 900.8 | |
| 0.00 | 1.07 | 0.00 | 0.62 | -22.82 | 259.55 | 3.67 | 186.73 | 0.5058 | -728.0 | -605.6 | |
| 0.00 | 0.98 | 0.00 | 0.56 | -21.81 | 259.46 | 3.58 | 186.81 | 0.4904 | 758.0 | 606.4 | |
| 0.00 | 2.24 | 0.00 | 1.24 | -19.04 | 259.33 | 3.45 | 187.33 | 0.4476 | 724.0 | 544.4 | |
| 8.41 | 11.72 | 4.70 | 6.55 | -20.09 | 259.19 | 3.31 | 186.75 | 0.4636 | 915.5 | 606.1 | |
| 25.68 | 151.28 | 14.29 | 84.10 | -19.74 | 258.73 | 2.85 | 185.90 | 0.4575 | 1073.9 | 216.5 | |
| 2.06 | -12.00 | 1.14 | -12.00 | -19.27 | 258.72 | 2.85 | 186.00 | 0.4501 | 1054.0 | 999999 | |
| 0.00 | 0.89 | 0.00 | 0.51 | -21.59 | 258.77 | 2.89 | 185.56 | 0.4860 | 670.0 | 586.3 | |
| 1.43 | -12.00 | 0.79 | -12.00 | -19.54 | 258.28 | 2.40 | 185.01 | 0.4536 | 809.6 | 999999 | |
| 0.00 | 1.79 | 0.00 | 1.03 | -23.16 | 258.17 | 2.30 | 184.17 | 0.5089 | 816.0 | 660.1 | |
| 0.00 | 2.06 | 0.00 | 1.12 | -17.65 | 258.06 | 2.18 | 184.93 | 0.4238 | -849.0 | -604.5 | |
| 0.00 | 1.70 | 0.00 | 0.97 | -22.95 | 258.04 | 2.16 | 183.95 | 0.5056 | 781.0 | 553.1 | |
| 0.00 | 0.81 | 0.00 | 0.44 | -17.95 | 257.87 | 2.00 | 184.45 | 0.4283 | -814.0 | -686.9 | |
| 0.00 | 1.07 | 0.00 | 0.61 | -22.00 | 257.57 | 1.69 | 183.20 | 0.4908 | 840.0 | 655.5 | |
| 0.00 | 5.10 | 0.00 | 2.81 | -18.62 | 257.40 | 1.52 | 183.31 | 0.4383 | -368.0 | -369.3 | |
| 0.00 | 1.07 | 0.00 | 0.59 | -17.71 | 257.30 | 1.42 | 183.21 | 0.4239 | -961.0 | -724.3 | |
| 3.58 | 4.47 | 1.97 | 2.47 | -18.86 | 257.28 | 1.40 | 183.01 | 0.4419 | -643.6 | -182.4 | |
| 7.60 | -12.00 | 4.21 | -12.00 | -19.26 | 257.25 | 1.37 | 182.90 | 0.4482 | -641.2 | 999999 | |
| 1.16 | -12.00 | 0.64 | -12.00 | -19.43 | 257.25 | 1.37 | 182.88 | 0.4509 | 100.1 | 999999 | |
| 0.00 | 1.34 | 0.00 | 0.74 | -18.48 | 257.08 | 1.20 | 182.63 | 0.4359 | -901.0 | -792.1 | |
| 0.00 | 1.70 | 0.00 | 0.93 | -18.22 | 256.98 | 1.11 | 182.45 | 0.4316 | -871.0 | -646.2 | |
| 0.00 | 1.97 | 0.00 | 1.07 | -17.61 | 256.82 | 0.94 | 182.14 | 0.4220 | -1014.0 | -806.6 | |
| 2.33 | 38.56 | 1.28 | 21.29 | -18.55 | 256.44 | 0.57 | 181.23 | 0.4366 | -1047.7 | -742.9 | |
| 0.00 | 1.34 | 0.00 | 0.75 | -20.07 | 256.45 | 0.57 | 181.17 | 0.4605 | -644.0 | -489.5 | |
| 12.08 | -29.00 | 6.66 | -29.00 | -18.89 | 256.32 | 0.44 | 180.95 | 0.4419 | -1060.0 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.60 | -20.21 | 256.32 | 0.44 | 180.90 | 0.4626 | -661.0 | -571.8 | |
| 0.00 | 2.50 | 0.00 | 1.39 | -19.46 | 256.32 | 0.44 | 180.93 | 0.4509 | -678.0 | -580.5 | |
| 0.00 | 0.81 | 0.00 | 0.45 | -20.59 | 256.16 | 0.28 | 180.57 | 0.4684 | -605.0 | -492.1 | |
| 2.15 | 6.62 | 1.19 | 3.67 | -19.56 | 255.96 | 0.09 | 180.18 | 0.4524 | -724.5 | -678.1 | |
| 0.00 | 1.34 | 0.00 | 0.74 | -18.92 | 255.87 | -0.01 | 179.98 | 0.4424 | -621.0 | -498.9 | |
| 0.00 | 2.42 | 0.00 | 1.34 | -19.67 | 255.26 | -0.62 | 178.71 | 0.4541 | -878.0 | -573.0 | |
| 0.00 | 0.81 | 0.00 | 0.44 | -17.31 | 255.17 | -0.70 | 178.38 | 0.4171 | -735.0 | -594.8 | |
| 0.00 | 1.34 | 0.00 | 0.74 | -19.09 | 254.33 | -1.54 | 176.71 | 0.4458 | -778.0 | -575.7 | |
| 0.00 | 1.25 | 0.00 | 0.68 | -17.08 | 254.10 | -1.78 | 175.87 | 0.4143 | -710.0 | -639.6 | |
| 0.00 | 1.25 | 0.00 | 0.68 | -15.83 | 253.13 | -2.74 | 173.29 | 0.3958 | -792.0 | -656.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
