SDO HMI 2011-09-03 15:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.28 | 17.14 | 3.42 | 11.17 | 13.28 | 292.13 | 40.66 | 282.04 | 0.6506 | -656.7 | -559.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-09-03 15:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.34 | 0.00 | 0.89 | 13.20 | 293.69 | 42.21 | 281.74 | 0.6704 | -525.0 | -470.1 | |
| 0.00 | 0.71 | 0.00 | 0.47 | 13.26 | 293.28 | 41.81 | 281.88 | 0.6654 | -150.0 | -199.6 | |
| 1.97 | 2.32 | 1.28 | 1.51 | 13.13 | 292.22 | 40.74 | 281.80 | 0.6516 | -713.2 | -638.5 | |
| 0.00 | 1.07 | 0.00 | 0.70 | 13.70 | 292.34 | 40.86 | 282.66 | 0.6538 | -380.0 | -374.9 | |
| 0.00 | 1.16 | 0.00 | 0.76 | 13.45 | 292.12 | 40.64 | 282.29 | 0.6507 | -782.0 | -672.2 | |
| 0.00 | 1.07 | 0.00 | 0.70 | 13.43 | 291.95 | 40.48 | 282.29 | 0.6485 | -854.0 | -690.9 | |
| 3.31 | 8.22 | 2.14 | 5.33 | 13.14 | 291.77 | 40.30 | 281.86 | 0.6458 | -890.9 | -625.0 | |
| 0.00 | 1.25 | 0.00 | 0.81 | 13.95 | 291.94 | 40.46 | 283.10 | 0.6489 | -676.0 | -530.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
