SDO HMI 2011-09-04 04:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34.15 | 156.39 | 31.42 | 147.57 | 23.38 | 302.67 | 58.36 | 293.26 | 0.8503 | -130.6 | -50.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-09-04 04:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.54 | 114.01 | 0.54 | 114.23 | 22.55 | 305.53 | 61.22 | 291.84 | 0.8740 | 120.5 | -182.8 | |
| 20.74 | -1.00 | 20.77 | -1.00 | 22.66 | 305.13 | 60.82 | 291.99 | 0.8710 | -775.9 | 999999 | |
| 0.00 | 0.45 | 0.00 | 0.43 | 22.78 | 303.96 | 59.65 | 292.25 | 0.8616 | -492.0 | -471.8 | |
| 0.00 | 1.25 | 0.00 | 1.00 | 25.15 | 295.08 | 50.77 | 296.50 | 0.7857 | 465.0 | 381.2 | |
| 1.61 | 2.59 | 1.29 | 2.08 | 25.68 | 295.34 | 51.03 | 297.10 | 0.7893 | 415.8 | 371.4 | |
| 0.00 | 3.93 | 0.00 | 3.12 | 25.01 | 294.84 | 50.53 | 296.38 | 0.7831 | 611.0 | 508.8 | |
| 0.00 | 1.61 | 0.00 | 1.28 | 25.52 | 295.03 | 50.72 | 296.97 | 0.7860 | 584.0 | 538.1 | |
| 0.00 | 2.32 | 0.00 | 1.84 | 25.75 | 294.58 | 50.27 | 297.37 | 0.7822 | 483.0 | 422.5 | |
| 3.13 | 3.13 | 2.46 | 2.46 | 25.85 | 294.22 | 49.91 | 297.58 | 0.7790 | 468.7 | 0.0 | |
| 2.77 | 5.37 | 2.20 | 4.27 | 26.60 | 294.61 | 50.30 | 298.42 | 0.7845 | 477.1 | 300.3 | |
| 1.79 | 2.86 | 1.39 | 2.23 | 25.60 | 293.81 | 49.50 | 297.36 | 0.7744 | 658.3 | 716.8 | |
| 0.00 | 2.06 | 0.00 | 1.61 | 25.91 | 293.99 | 49.68 | 297.70 | 0.7769 | 440.0 | 404.0 | |
| 0.00 | 1.88 | 0.00 | 1.45 | 25.20 | 293.23 | 48.92 | 296.99 | 0.7677 | 660.0 | 582.1 | |
| 2.50 | 6.17 | 1.95 | 4.80 | 26.26 | 293.67 | 49.36 | 298.23 | 0.7747 | 520.5 | 529.4 | |
| 0.00 | 1.34 | 0.00 | 1.04 | 25.94 | 293.28 | 48.97 | 297.93 | 0.7700 | 677.0 | 589.1 | |
| 0.00 | 1.52 | 0.00 | 1.16 | 25.56 | 292.81 | 48.50 | 297.56 | 0.7645 | 605.0 | 547.9 | |
| 0.00 | 1.61 | 0.00 | 1.24 | 26.02 | 293.07 | 48.76 | 298.09 | 0.7682 | 676.0 | 592.4 | |
| 0.00 | 2.68 | 0.00 | 2.09 | 26.88 | 293.41 | 49.10 | 299.08 | 0.7737 | 591.0 | 538.5 | |
| 1.07 | 1.61 | 0.82 | 1.24 | 26.27 | 292.85 | 48.54 | 298.46 | 0.7667 | 660.8 | 618.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
