SDO HMI 2011-09-05 17:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.32 | 73.00 | 8.42 | 49.59 | -19.46 | 258.56 | 34.61 | 231.35 | 0.6879 | 188.8 | 336.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-09-05 17:59:07 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.62 | 0.00 | 0.46 | -21.96 | 261.81 | 37.85 | 230.85 | 0.7361 | 583.0 | 542.7 | |
| 0.00 | 0.98 | 0.00 | 0.71 | -23.02 | 260.82 | 36.87 | 228.96 | 0.7344 | 597.0 | 407.5 | |
| 0.00 | 1.16 | 0.00 | 0.79 | -18.07 | 259.14 | 35.19 | 233.48 | 0.6840 | -561.0 | -441.7 | |
| 9.82 | 48.20 | 6.72 | 32.86 | -19.53 | 258.94 | 34.99 | 231.57 | 0.6923 | 915.3 | 611.8 | |
| 1.16 | 3.30 | 0.80 | 2.28 | -20.01 | 259.07 | 35.11 | 231.09 | 0.6969 | 439.5 | 424.0 | |
| 0.00 | 1.25 | 0.00 | 0.84 | -18.70 | 258.55 | 34.59 | 232.27 | 0.6823 | 748.0 | 519.3 | |
| 1.34 | 4.46 | 0.90 | 3.00 | -18.43 | 258.14 | 34.18 | 232.27 | 0.6763 | -429.9 | 23.8 | |
| 0.00 | 1.16 | 0.00 | 0.82 | -23.27 | 258.66 | 34.71 | 227.05 | 0.7170 | 560.0 | 483.1 | |
| 0.00 | 3.03 | 0.00 | 2.03 | -18.94 | 257.41 | 33.46 | 231.05 | 0.6727 | -663.0 | -514.8 | |
| 0.00 | 1.07 | 0.00 | 0.71 | -18.67 | 256.85 | 32.90 | 230.93 | 0.6651 | -671.0 | -617.0 | |
| 0.00 | 0.27 | 0.00 | 0.19 | -25.08 | 258.06 | 34.10 | 224.60 | 0.7256 | 576.0 | 533.3 | |
| 0.00 | 3.75 | 0.00 | 2.45 | -18.32 | 256.21 | 32.25 | 230.82 | 0.6559 | -775.0 | -468.9 | |
| 0.00 | 0.80 | 0.00 | 0.53 | -19.44 | 256.37 | 32.42 | 229.59 | 0.6663 | -600.0 | -472.9 | |
| 0.00 | 1.25 | 0.00 | 0.81 | -17.40 | 255.79 | 31.84 | 231.62 | 0.6445 | -655.0 | -530.1 | |
| 0.00 | 0.54 | 0.00 | 0.35 | -17.67 | 255.47 | 31.52 | 231.00 | 0.6433 | -499.0 | -584.5 | |
| 0.00 | 1.16 | 0.00 | 0.76 | -19.58 | 255.57 | 31.62 | 228.73 | 0.6595 | -712.0 | -559.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
