SDO HMI 2011-10-06 08:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.70 | 9.93 | 0.45 | 6.29 | -12.95 | 146.17 | -33.53 | 120.30 | 0.6256 | -1.2 | 0.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-06 08:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.37 | 0.00 | 1.47 | -12.96 | 148.03 | -31.67 | 121.71 | 0.6037 | 762.0 | 591.3 | |
| 0.00 | 1.41 | 0.00 | 0.88 | -13.48 | 147.85 | -31.85 | 122.31 | 0.6094 | 320.0 | 327.2 | |
| 0.00 | 1.23 | 0.00 | 0.77 | -13.99 | 147.37 | -32.33 | 122.64 | 0.6186 | 619.0 | 537.1 | |
| 0.70 | 2.72 | 0.45 | 1.74 | -12.20 | 145.09 | -34.61 | 118.43 | 0.6335 | -789.2 | -672.3 | |
| 0.00 | 2.20 | 0.00 | 1.43 | -12.95 | 143.88 | -35.82 | 118.64 | 0.6522 | -563.0 | -488.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
