SDO HMI 2011-10-06 23:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.48 | 172.05 | 17.10 | 90.58 | -11.33 | 179.81 | 8.37 | 205.03 | 0.3392 | 598.9 | 281.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-06 23:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.81 | 153.70 | 16.22 | 80.95 | -11.20 | 180.50 | 9.06 | 207.10 | 0.3404 | 1188.6 | 409.4 | |
| 0.97 | -1.00 | 0.51 | -1.00 | -11.16 | 180.07 | 8.62 | 206.03 | 0.3367 | 947.8 | 999999 | |
| 0.70 | 2.11 | 0.37 | 1.11 | -11.34 | 179.64 | 8.20 | 204.67 | 0.3364 | 961.9 | 869.6 | |
| 0.00 | 2.28 | 0.00 | 1.21 | -13.85 | 173.80 | 2.36 | 186.57 | 0.3505 | -689.0 | -592.8 | |
| 0.00 | 2.02 | 0.00 | 1.06 | -12.35 | 173.75 | 2.31 | 186.97 | 0.3260 | -879.0 | -788.3 | |
| 0.00 | 1.67 | 0.00 | 0.87 | -12.58 | 173.66 | 2.22 | 186.62 | 0.3294 | -700.0 | -520.4 | |
| 0.00 | 2.90 | 0.00 | 1.52 | -12.35 | 173.51 | 2.07 | 186.24 | 0.3255 | -1045.0 | -858.5 | |
| 0.00 | 1.49 | 0.00 | 0.79 | -13.82 | 173.52 | 2.08 | 185.81 | 0.3495 | -912.0 | -757.2 | |
| 0.00 | 4.21 | 0.00 | 2.20 | -12.10 | 172.99 | 1.54 | 184.73 | 0.3204 | -893.0 | -771.0 | |
| 0.00 | 1.67 | 0.00 | 0.87 | -11.91 | 172.68 | 1.24 | 183.84 | 0.3169 | -929.0 | -789.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
