SDO HMI 2011-10-07 01:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 56.71 | 323.14 | 30.25 | 172.74 | 23.24 | 155.55 | -14.79 | 38.67 | 0.3768 | -750.3 | -342.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-07 01:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.14 | 0.00 | 0.59 | 19.77 | 157.71 | -12.63 | 41.43 | 0.3124 | -809.0 | -563.3 | |
| 14.40 | 291.05 | 7.66 | 155.23 | 22.93 | 156.16 | -14.18 | 38.18 | 0.3667 | -1365.5 | -399.0 | |
| 0.00 | 1.05 | 0.00 | 0.57 | 26.74 | 155.63 | -14.71 | 32.91 | 0.4191 | -582.0 | -454.1 | |
| 0.00 | 1.32 | 0.00 | 0.72 | 26.04 | 155.52 | -14.82 | 34.16 | 0.4112 | -813.0 | -765.8 | |
| 36.52 | -2.00 | 19.50 | -2.00 | 23.29 | 155.81 | -14.53 | 38.15 | 0.3746 | -1285.5 | 999999 | |
| 0.00 | 1.40 | 0.00 | 0.76 | 26.29 | 155.45 | -14.89 | 33.89 | 0.4150 | -864.0 | -618.4 | |
| 0.00 | 1.58 | 0.00 | 0.86 | 26.73 | 155.08 | -15.26 | 33.87 | 0.4237 | -934.0 | -674.7 | |
| 0.00 | 1.14 | 0.00 | 0.62 | 25.55 | 155.13 | -15.21 | 35.57 | 0.4086 | -723.0 | -622.7 | |
| 5.79 | -2.00 | 3.09 | -2.00 | 22.47 | 155.44 | -14.91 | 40.36 | 0.3687 | -945.9 | 999999 | |
| 0.00 | 1.05 | 0.00 | 0.57 | 25.95 | 154.63 | -15.71 | 35.78 | 0.4182 | -643.0 | -533.8 | |
| 0.00 | 1.14 | 0.00 | 0.61 | 22.57 | 154.41 | -15.93 | 41.96 | 0.3806 | -730.0 | -593.3 | |
| 0.00 | 1.93 | 0.00 | 1.04 | 24.35 | 154.16 | -16.18 | 39.18 | 0.4037 | -1037.0 | -708.0 | |
| 0.00 | 1.05 | 0.00 | 0.57 | 23.74 | 153.69 | -16.65 | 41.00 | 0.4015 | -692.0 | -545.1 | |
| 0.00 | 2.37 | 0.00 | 1.27 | 22.67 | 153.79 | -16.55 | 42.79 | 0.3886 | 840.0 | 677.5 | |
| 0.00 | 1.23 | 0.00 | 0.66 | 22.95 | 153.72 | -16.62 | 42.38 | 0.3924 | 990.0 | 782.6 | |
| 0.00 | 1.49 | 0.00 | 0.81 | 24.13 | 153.26 | -17.08 | 40.99 | 0.4104 | -547.0 | -468.8 | |
| 0.00 | 1.40 | 0.00 | 0.77 | 25.04 | 152.09 | -18.25 | 41.19 | 0.4327 | -632.0 | -494.9 | |
| 0.00 | 2.19 | 0.00 | 1.19 | 22.99 | 151.88 | -18.47 | 45.14 | 0.4131 | 768.0 | 700.9 | |
| 0.00 | 1.40 | 0.00 | 0.77 | 23.26 | 151.56 | -18.78 | 45.09 | 0.4195 | 612.0 | 469.1 | |
| 0.00 | 2.28 | 0.00 | 1.27 | 25.31 | 150.68 | -19.66 | 42.72 | 0.4503 | 1041.0 | 780.4 | |
| 0.00 | 1.32 | 0.00 | 0.73 | 25.15 | 150.50 | -19.85 | 43.24 | 0.4505 | 820.0 | 678.7 | |
| 0.00 | 1.14 | 0.00 | 0.62 | 22.57 | 150.77 | -19.58 | 47.46 | 0.4217 | 791.0 | 614.3 | |
| 0.00 | 1.05 | 0.00 | 0.58 | 23.14 | 150.02 | -20.32 | 47.38 | 0.4358 | 773.0 | 648.3 | |
| 0.00 | 1.40 | 0.00 | 0.79 | 25.42 | 148.42 | -21.92 | 45.39 | 0.4755 | 837.0 | 729.6 | |
| 0.00 | 2.02 | 0.00 | 1.14 | 25.19 | 148.25 | -22.09 | 45.97 | 0.4752 | 779.0 | 652.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
