SDO HMI 2011-10-07 12:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.12 | 155.60 | 17.42 | 84.33 | -11.27 | 180.37 | 16.06 | 222.11 | 0.4060 | 671.9 | 300.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-07 12:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.19 | 144.53 | 16.37 | 78.43 | -11.20 | 180.80 | 16.49 | 223.09 | 0.4092 | 1140.9 | 366.7 | |
| 1.23 | -1.00 | 0.67 | -1.00 | -11.37 | 180.43 | 16.12 | 222.14 | 0.4073 | 962.6 | 999999 | |
| 0.70 | -1.00 | 0.38 | -1.00 | -11.12 | 180.22 | 15.91 | 222.21 | 0.4021 | 1083.2 | 999999 | |
| 0.00 | 1.76 | 0.00 | 0.95 | -11.17 | 179.97 | 15.66 | 221.67 | 0.4000 | 918.0 | 797.7 | |
| 0.00 | 1.67 | 0.00 | 0.90 | -13.19 | 176.64 | 12.32 | 212.00 | 0.3939 | -679.0 | -499.3 | |
| 0.00 | 2.90 | 0.00 | 1.53 | -11.41 | 174.53 | 10.21 | 209.77 | 0.3516 | -899.0 | -590.4 | |
| 0.00 | 0.35 | 0.00 | 0.19 | -14.06 | 174.17 | 9.85 | 205.52 | 0.3870 | -598.0 | -517.0 | |
| 0.00 | 1.14 | 0.00 | 0.61 | -12.25 | 174.03 | 9.72 | 207.42 | 0.3597 | -826.0 | -699.0 | |
| 0.00 | 1.14 | 0.00 | 0.61 | -14.31 | 173.58 | 9.27 | 203.91 | 0.3866 | -732.0 | -533.5 | |
| 0.00 | 2.11 | 0.00 | 1.11 | -11.85 | 172.84 | 8.52 | 204.96 | 0.3453 | -921.0 | -754.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
