SDO HMI 2011-10-07 22:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 71.22 | 317.88 | 50.34 | 224.85 | -15.01 | 118.36 | -40.43 | 118.58 | 0.7142 | 281.0 | 138.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-07 22:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.79 | 178.77 | 24.27 | 121.09 | -15.25 | 121.22 | -37.57 | 120.49 | 0.6851 | 1096.3 | 359.5 | |
| 1.05 | -1.00 | 0.71 | -1.00 | -14.74 | 121.25 | -37.55 | 119.84 | 0.6818 | 757.6 | 999999 | |
| 0.00 | 4.65 | 0.00 | 3.21 | -15.66 | 120.07 | -38.73 | 120.28 | 0.7000 | 685.0 | 547.6 | |
| 0.00 | 2.81 | 0.00 | 1.95 | -15.49 | 119.74 | -39.06 | 119.86 | 0.7025 | 633.0 | 514.3 | |
| 9.65 | 21.40 | 6.70 | 14.85 | -15.12 | 119.50 | -39.29 | 119.24 | 0.7030 | 821.8 | 503.2 | |
| 0.00 | 2.02 | 0.00 | 1.41 | -14.59 | 118.90 | -39.90 | 118.20 | 0.7068 | 783.0 | 467.6 | |
| 0.00 | 0.96 | 0.00 | 0.68 | -14.98 | 118.81 | -39.99 | 118.65 | 0.7098 | 596.0 | 443.1 | |
| 2.98 | 3.86 | 2.10 | 2.72 | -15.25 | 118.67 | -40.13 | 118.90 | 0.7127 | 536.8 | 469.2 | |
| 0.00 | 1.23 | 0.00 | 0.89 | -14.62 | 116.79 | -42.01 | 117.06 | 0.7295 | -792.0 | -666.4 | |
| 0.00 | 1.40 | 0.00 | 1.01 | -14.46 | 116.83 | -41.97 | 116.88 | 0.7283 | -654.0 | -596.9 | |
| 2.81 | 3.42 | 2.02 | 2.46 | -14.15 | 116.69 | -42.11 | 116.42 | 0.7283 | -680.9 | -666.1 | |
| 0.00 | 1.23 | 0.00 | 0.89 | -14.76 | 116.25 | -42.55 | 116.95 | 0.7358 | -676.0 | -527.1 | |
| 0.00 | 0.70 | 0.00 | 0.51 | -13.76 | 116.45 | -42.35 | 115.79 | 0.7291 | 603.0 | 460.6 | |
| 0.00 | 1.14 | 0.00 | 0.85 | -15.54 | 115.33 | -43.47 | 117.43 | 0.7491 | -521.0 | -410.1 | |
| 0.00 | 2.98 | 0.00 | 2.24 | -15.02 | 114.60 | -44.20 | 116.42 | 0.7541 | -716.0 | -507.9 | |
| 0.00 | 3.77 | 0.00 | 2.86 | -15.43 | 114.32 | -44.48 | 116.78 | 0.7588 | -473.0 | -480.4 | |
| 0.00 | 2.02 | 0.00 | 1.52 | -14.91 | 114.42 | -44.38 | 116.19 | 0.7556 | -730.0 | -543.3 | |
| 0.00 | 0.61 | 0.00 | 0.46 | -14.42 | 114.45 | -44.35 | 115.62 | 0.7531 | -614.0 | -587.4 | |
| 0.70 | 2.89 | 0.53 | 2.17 | -14.02 | 114.34 | -44.46 | 115.06 | 0.7525 | -593.6 | -637.6 | |
| 2.19 | 2.37 | 1.68 | 1.82 | -15.52 | 113.59 | -45.21 | 116.53 | 0.7666 | -525.5 | -638.0 | |
| 16.05 | 78.42 | 12.33 | 60.30 | -14.56 | 113.23 | -45.57 | 115.19 | 0.7661 | -867.2 | -236.7 | |
| 0.00 | 1.23 | 0.00 | 0.96 | -13.88 | 111.84 | -46.96 | 113.74 | 0.7774 | -560.0 | -384.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
