SDO HMI 2011-10-08 02:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 52.03 | 300.85 | 26.96 | 156.02 | 23.44 | 155.10 | -1.50 | 4.52 | 0.2965 | -877.2 | -367.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-08 02:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.81 | 0.00 | 1.46 | 24.01 | 157.96 | 1.36 | 355.91 | 0.3052 | -802.0 | -715.3 | |
| 0.53 | 3.07 | 0.28 | 1.61 | 25.28 | 157.64 | 1.04 | 357.10 | 0.3259 | -941.8 | -724.7 | |
| 0.00 | 1.23 | 0.00 | 0.65 | 26.55 | 156.31 | -0.29 | 0.74 | 0.3465 | -1025.0 | -844.1 | |
| 0.00 | 1.58 | 0.00 | 0.81 | 21.55 | 156.26 | -0.34 | 1.21 | 0.2630 | 807.0 | 550.7 | |
| 10.00 | 223.87 | 5.17 | 115.90 | 23.04 | 155.83 | -0.77 | 2.46 | 0.2884 | -1439.0 | -423.1 | |
| 0.00 | 3.33 | 0.00 | 1.75 | 26.01 | 155.48 | -1.12 | 2.99 | 0.3380 | -894.0 | -783.6 | |
| 33.08 | -5.00 | 17.13 | -5.00 | 23.26 | 155.41 | -1.19 | 3.76 | 0.2925 | -1448.1 | 999999 | |
| 0.00 | 1.05 | 0.00 | 0.54 | 21.64 | 155.42 | -1.18 | 4.15 | 0.2652 | -676.0 | -427.8 | |
| 0.00 | 1.40 | 0.00 | 0.74 | 25.82 | 155.22 | -1.38 | 3.73 | 0.3351 | -835.0 | -657.4 | |
| 2.72 | 29.49 | 1.40 | 15.21 | 22.39 | 155.06 | -1.54 | 5.15 | 0.2783 | -1090.1 | -393.1 | |
| 0.00 | 1.58 | 0.00 | 0.83 | 26.39 | 154.81 | -1.79 | 4.68 | 0.3450 | -560.0 | -456.5 | |
| 0.00 | 1.76 | 0.00 | 0.92 | 25.05 | 153.34 | -3.26 | 9.14 | 0.3259 | -797.0 | -687.8 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 24.10 | 153.17 | -3.43 | 10.17 | 0.3109 | -863.0 | -622.1 | |
| 0.00 | 0.88 | 0.00 | 0.46 | 25.20 | 153.14 | -3.46 | 9.61 | 0.3290 | -609.0 | -387.5 | |
| 0.00 | 2.46 | 0.00 | 1.30 | 26.09 | 152.61 | -3.99 | 10.49 | 0.3449 | 976.0 | 758.8 | |
| 5.70 | 8.25 | 2.98 | 4.31 | 24.60 | 152.39 | -4.21 | 12.03 | 0.3215 | -906.9 | -596.6 | |
| 0.00 | 3.60 | 0.00 | 1.88 | 24.47 | 152.10 | -4.50 | 12.93 | 0.3205 | -1034.0 | -852.7 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 24.72 | 152.03 | -4.57 | 12.94 | 0.3248 | -566.0 | -458.7 | |
| 0.00 | 6.06 | 0.00 | 3.19 | 25.89 | 151.81 | -4.79 | 12.65 | 0.3443 | 978.0 | 868.0 | |
| 0.00 | 2.02 | 0.00 | 1.06 | 25.59 | 150.36 | -6.24 | 16.56 | 0.3456 | 776.0 | 672.3 | |
| 0.00 | 1.76 | 0.00 | 0.90 | 21.11 | 150.28 | -6.32 | 21.95 | 0.2762 | 888.0 | 750.0 | |
| 0.00 | 1.23 | 0.00 | 0.65 | 25.74 | 149.18 | -7.42 | 19.29 | 0.3537 | 855.0 | 672.4 | |
| 0.00 | 1.32 | 0.00 | 0.75 | 33.84 | 144.84 | -11.75 | 20.07 | 0.4952 | 743.0 | 537.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
