SDO HMI 2011-10-08 03:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 53.27 | 287.79 | 27.59 | 149.32 | 23.52 | 154.96 | -1.09 | 3.21 | 0.2977 | -792.2 | -372.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-08 03:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.25 | 0.00 | 1.69 | 23.97 | 157.97 | 1.91 | 354.24 | 0.3055 | -900.0 | -702.3 | |
| 0.00 | 4.12 | 0.00 | 2.16 | 25.24 | 157.79 | 1.74 | 355.16 | 0.3261 | -940.0 | -726.7 | |
| 0.00 | 0.97 | 0.00 | 0.51 | 26.58 | 156.37 | 0.31 | 359.18 | 0.3470 | -927.0 | -790.0 | |
| 0.00 | 0.79 | 0.00 | 0.41 | 21.60 | 156.32 | 0.27 | 359.04 | 0.2641 | 638.0 | 548.3 | |
| 9.92 | 207.03 | 5.13 | 107.18 | 23.04 | 155.77 | -0.28 | 0.90 | 0.2882 | -1449.8 | -450.0 | |
| 0.00 | 2.02 | 0.00 | 1.09 | 30.23 | 155.65 | -0.40 | 0.86 | 0.4064 | -767.0 | -606.7 | |
| 0.00 | 1.58 | 0.00 | 0.83 | 26.13 | 155.50 | -0.55 | 1.47 | 0.3397 | -937.0 | -814.7 | |
| 34.40 | -5.00 | 17.81 | -5.00 | 23.29 | 155.41 | -0.64 | 2.02 | 0.2926 | -1445.8 | 999999 | |
| 4.04 | 27.29 | 2.08 | 14.07 | 22.32 | 155.09 | -0.96 | 3.22 | 0.2765 | -1042.0 | -387.6 | |
| 0.00 | 0.79 | 0.00 | 0.42 | 26.83 | 154.92 | -1.13 | 2.88 | 0.3516 | 590.0 | 424.3 | |
| 0.00 | 1.49 | 0.00 | 0.79 | 26.42 | 154.76 | -1.29 | 3.37 | 0.3450 | -676.0 | -473.6 | |
| 0.00 | 2.72 | 0.00 | 1.42 | 25.01 | 153.35 | -2.70 | 7.60 | 0.3241 | -899.0 | -674.7 | |
| 0.00 | 1.84 | 0.00 | 0.96 | 24.50 | 152.67 | -3.38 | 9.77 | 0.3175 | -714.0 | -648.9 | |
| 0.00 | 2.37 | 0.00 | 1.25 | 26.12 | 152.56 | -3.49 | 9.19 | 0.3440 | 976.0 | 722.6 | |
| 4.91 | 12.55 | 2.57 | 6.56 | 24.60 | 152.41 | -3.65 | 10.46 | 0.3197 | -918.9 | -724.5 | |
| 0.00 | 2.11 | 0.00 | 1.10 | 24.72 | 152.00 | -4.05 | 11.50 | 0.3230 | -633.0 | -488.4 | |
| 0.00 | 0.97 | 0.00 | 0.51 | 24.97 | 152.00 | -4.05 | 11.35 | 0.3271 | -501.0 | -446.9 | |
| 0.00 | 0.97 | 0.00 | 0.50 | 22.43 | 151.98 | -4.07 | 13.34 | 0.2859 | 880.0 | 740.5 | |
| 0.00 | 5.53 | 0.00 | 2.91 | 25.92 | 151.80 | -4.25 | 11.26 | 0.3431 | 1079.0 | 869.4 | |
| 0.00 | 3.95 | 0.00 | 2.03 | 21.11 | 150.28 | -5.78 | 20.21 | 0.2729 | 678.0 | 668.3 | |
| 0.00 | 0.97 | 0.00 | 0.50 | 21.91 | 149.92 | -6.13 | 20.25 | 0.2876 | 807.0 | 616.0 | |
| 0.00 | 1.67 | 0.00 | 0.88 | 25.74 | 149.16 | -6.89 | 18.00 | 0.3510 | 801.0 | 644.6 | |
| 0.00 | 1.14 | 0.00 | 0.60 | 25.53 | 147.90 | -8.15 | 21.22 | 0.3548 | 734.0 | 560.7 | |
| 0.00 | 1.67 | 0.00 | 0.95 | 33.73 | 142.57 | -13.48 | 22.75 | 0.5032 | 726.0 | 555.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
