SDO HMI 2011-10-08 06:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.22 | 134.54 | 14.09 | 78.27 | -11.25 | 180.67 | 26.26 | 236.09 | 0.5248 | 693.4 | 310.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-08 06:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.70 | 126.12 | 0.41 | 73.47 | -11.33 | 181.22 | 26.81 | 236.57 | 0.5320 | 623.1 | 333.2 | |
| 23.52 | -1.00 | 13.68 | -1.00 | -11.18 | 180.86 | 26.45 | 236.44 | 0.5264 | 1106.4 | 999999 | |
| 0.00 | 2.72 | 0.00 | 1.57 | -10.75 | 180.31 | 25.90 | 236.59 | 0.5161 | 650.0 | 761.6 | |
| 0.00 | 1.05 | 0.00 | 0.61 | -11.19 | 179.70 | 25.30 | 235.24 | 0.5123 | 698.0 | 584.3 | |
| 0.00 | 0.79 | 0.00 | 0.45 | -12.39 | 177.20 | 22.79 | 230.42 | 0.4929 | -620.0 | -411.8 | |
| 0.00 | 1.23 | 0.00 | 0.69 | -12.70 | 174.85 | 20.44 | 226.83 | 0.4691 | -925.0 | -741.5 | |
| 0.00 | 1.49 | 0.00 | 0.84 | -13.69 | 174.84 | 20.43 | 225.28 | 0.4792 | -566.0 | -437.5 | |
| 0.00 | 1.14 | 0.00 | 0.64 | -14.32 | 173.91 | 19.50 | 223.00 | 0.4762 | -628.0 | -550.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
