SDO HMI 2011-10-08 11:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 43.77 | 247.18 | 22.70 | 128.38 | 23.43 | 154.97 | 3.30 | 349.68 | 0.3012 | -670.1 | -372.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-08 11:59:03 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.93 | 0.00 | 1.02 | 25.03 | 158.04 | 6.37 | 342.62 | 0.3382 | -803.0 | -682.3 | |
| 0.00 | 0.96 | 0.00 | 0.50 | 24.21 | 157.80 | 6.13 | 342.43 | 0.3242 | -738.0 | -607.5 | |
| 0.00 | 1.32 | 0.00 | 0.68 | 21.76 | 156.56 | 4.89 | 343.45 | 0.2792 | 747.0 | 461.6 | |
| 9.21 | 210.25 | 4.77 | 109.07 | 23.04 | 155.63 | 3.96 | 347.57 | 0.2961 | -1303.0 | -439.6 | |
| 29.56 | -4.00 | 15.34 | -4.00 | 23.29 | 155.27 | 3.60 | 348.82 | 0.2990 | -1319.7 | 999999 | |
| 2.54 | 4.65 | 1.31 | 2.40 | 22.27 | 154.86 | 3.19 | 349.39 | 0.2808 | -1005.5 | -832.0 | |
| 0.00 | 0.79 | 0.00 | 0.42 | 26.43 | 154.60 | 2.93 | 352.43 | 0.3483 | -681.0 | -561.6 | |
| 0.00 | 1.23 | 0.00 | 0.64 | 24.94 | 153.50 | 1.83 | 354.81 | 0.3220 | -626.0 | -480.4 | |
| 0.00 | 5.44 | 0.00 | 2.81 | 22.74 | 153.31 | 1.64 | 354.67 | 0.2851 | 351.0 | 392.4 | |
| 0.00 | 1.14 | 0.00 | 0.60 | 25.19 | 153.11 | 1.44 | 355.98 | 0.3256 | -788.0 | -607.2 | |
| 0.00 | 2.02 | 0.00 | 1.05 | 24.09 | 152.96 | 1.29 | 356.13 | 0.3072 | -906.0 | -764.9 | |
| 2.46 | 5.44 | 1.28 | 2.84 | 24.72 | 152.48 | 0.81 | 357.68 | 0.3172 | -925.9 | -709.5 | |
| 0.00 | 1.14 | 0.00 | 0.59 | 24.12 | 152.05 | 0.38 | 358.88 | 0.3070 | -723.0 | -482.9 | |
| 0.00 | 2.19 | 0.00 | 1.15 | 26.15 | 151.99 | 0.32 | 359.17 | 0.3406 | 998.0 | 850.8 | |
| 0.00 | 0.96 | 0.00 | 0.50 | 24.50 | 151.85 | 0.18 | 359.48 | 0.3133 | -686.0 | -414.7 | |
| 0.00 | 1.40 | 0.00 | 0.74 | 26.02 | 151.75 | 0.08 | 359.78 | 0.3385 | 904.0 | 748.8 | |
| 0.00 | 1.14 | 0.00 | 0.59 | 22.49 | 151.39 | -0.28 | 0.92 | 0.2797 | 864.0 | 712.3 | |
| 0.00 | 1.14 | 0.00 | 0.60 | 25.45 | 150.46 | -1.21 | 3.34 | 0.3296 | 885.0 | 638.6 | |
| 0.00 | 1.14 | 0.00 | 0.60 | 25.02 | 147.78 | -3.89 | 10.84 | 0.3281 | 769.0 | 596.1 | |
| 0.00 | 0.88 | 0.00 | 0.46 | 23.98 | 147.72 | -3.95 | 11.73 | 0.3114 | 771.0 | 581.8 | |
| 0.00 | 0.79 | 0.00 | 0.44 | 32.40 | 145.82 | -5.85 | 11.06 | 0.4503 | 617.0 | 540.8 | |
| 0.00 | 1.23 | 0.00 | 0.68 | 32.27 | 145.83 | -5.84 | 11.11 | 0.4482 | 735.0 | 529.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
