SDO HMI 2011-10-09 17:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.99 | 85.75 | 7.46 | 63.86 | -11.28 | 180.31 | 45.14 | 248.76 | 0.7479 | 243.8 | 264.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-09 17:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.58 | 76.38 | 1.18 | 57.18 | -11.33 | 180.82 | 45.64 | 248.94 | 0.7536 | 632.2 | 354.2 | |
| 8.41 | -1.00 | 6.28 | -1.00 | -11.06 | 180.63 | 45.46 | 249.19 | 0.7506 | 996.8 | 999999 | |
| 0.00 | 0.61 | 0.00 | 0.46 | -12.99 | 180.39 | 45.22 | 246.67 | 0.7555 | 648.0 | 493.9 | |
| 0.00 | 1.05 | 0.00 | 0.79 | -13.71 | 179.91 | 44.74 | 245.56 | 0.7534 | -446.0 | -377.7 | |
| 0.00 | 1.23 | 0.00 | 0.92 | -13.76 | 179.79 | 44.62 | 245.43 | 0.7524 | -656.0 | -539.0 | |
| 0.00 | 1.40 | 0.00 | 0.98 | -11.92 | 176.33 | 41.16 | 246.08 | 0.7068 | -427.0 | -394.0 | |
| 0.00 | 1.66 | 0.00 | 1.15 | -11.92 | 175.96 | 40.79 | 245.88 | 0.7027 | -714.0 | -598.4 | |
| 0.00 | 1.05 | 0.00 | 0.73 | -12.53 | 176.08 | 40.90 | 245.15 | 0.7068 | -682.0 | -468.7 | |
| 0.00 | 1.58 | 0.00 | 1.10 | -12.54 | 175.84 | 40.66 | 245.00 | 0.7042 | -401.0 | -455.1 | |
| 0.00 | 0.79 | 0.00 | 0.55 | -13.73 | 175.67 | 40.50 | 243.36 | 0.7081 | -559.0 | -433.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
