SDO HMI 2011-10-09 19:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 42.40 | 266.38 | 74.69 | 473.78 | 26.87 | 59.23 | -74.84 | 63.79 | 0.9609 | -439.5 | -111.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-09 19:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 28.12 | 264.45 | 49.06 | 470.28 | 26.98 | 59.43 | -74.64 | 63.68 | 0.9600 | -694.7 | -113.6 | |
| 9.90 | -1.00 | 17.91 | -1.00 | 27.00 | 58.72 | -75.35 | 63.66 | 0.9631 | 187.9 | 999999 | |
| 4.38 | -1.00 | 7.72 | -1.00 | 26.06 | 59.20 | -74.87 | 64.64 | 0.9609 | -445.8 | 999999 | |
| 0.00 | 1.14 | 0.00 | 2.00 | 24.81 | 59.24 | -74.83 | 65.94 | 0.9607 | 141.0 | 103.0 | |
| 0.00 | 0.79 | 0.00 | 1.50 | 24.30 | 57.86 | -76.21 | 66.47 | 0.9665 | 311.0 | 266.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
