SDO HMI 2011-10-09 20:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34.42 | 204.28 | 19.09 | 113.00 | 23.48 | 154.23 | 20.72 | 313.15 | 0.4464 | -528.5 | -338.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-09 20:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.45 | 0.00 | 1.41 | 27.48 | 156.85 | 23.33 | 316.46 | 0.5122 | -580.0 | -484.0 | |
| 7.62 | 182.56 | 4.23 | 101.17 | 23.09 | 155.09 | 21.58 | 311.24 | 0.4518 | -1106.6 | -448.6 | |
| 0.00 | 1.23 | 0.00 | 0.67 | 21.36 | 154.57 | 21.06 | 308.62 | 0.4301 | -806.0 | -667.0 | |
| 26.19 | -2.00 | 14.52 | -2.00 | 23.36 | 154.75 | 21.24 | 312.12 | 0.4502 | -1345.7 | 999999 | |
| 0.61 | -2.00 | 0.34 | -2.00 | 23.06 | 154.36 | 20.84 | 312.08 | 0.4428 | -1398.9 | 999999 | |
| 0.00 | 1.31 | 0.00 | 0.72 | 22.17 | 153.84 | 20.32 | 311.08 | 0.4284 | 644.0 | 536.1 | |
| 0.00 | 0.96 | 0.00 | 0.53 | 25.75 | 150.46 | 16.95 | 322.15 | 0.4296 | 735.0 | 554.5 | |
| 0.00 | 3.07 | 0.00 | 1.66 | 24.96 | 149.04 | 15.53 | 323.18 | 0.4067 | 717.0 | 546.2 | |
| 0.00 | 0.61 | 0.00 | 0.33 | 23.32 | 148.23 | 14.71 | 321.81 | 0.3789 | 641.0 | 549.6 | |
| 0.00 | 2.54 | 0.00 | 1.38 | 26.03 | 148.32 | 14.81 | 326.08 | 0.4132 | 764.0 | 608.7 | |
| 0.00 | 1.58 | 0.00 | 0.85 | 25.92 | 147.93 | 14.41 | 326.59 | 0.4083 | 974.0 | 808.0 | |
| 0.00 | 1.23 | 0.00 | 0.66 | 23.99 | 147.56 | 14.05 | 324.20 | 0.3808 | 994.0 | 811.2 | |
| 0.00 | 1.14 | 0.00 | 0.61 | 23.77 | 147.51 | 13.99 | 323.94 | 0.3775 | 973.0 | 703.5 | |
| 0.00 | 1.31 | 0.00 | 0.71 | 25.90 | 147.27 | 13.76 | 327.73 | 0.4024 | 792.0 | 624.4 | |
| 0.00 | 0.61 | 0.00 | 0.33 | 26.42 | 145.42 | 11.90 | 331.95 | 0.3945 | 646.0 | 513.4 | |
| 0.00 | 2.80 | 0.00 | 1.51 | 26.08 | 145.14 | 11.63 | 332.03 | 0.3877 | 759.0 | 694.1 | |
| 0.00 | 0.88 | 0.00 | 0.46 | 24.54 | 142.12 | 8.61 | 336.62 | 0.3444 | 826.0 | 607.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
