SDO HMI 2011-10-10 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 103.21 | 611.51 | 53.58 | 317.57 | 23.18 | 121.23 | -4.05 | 12.52 | 0.3008 | -1272.9 | -417.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-10 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 103.21 | 607.58 | 53.58 | 315.51 | 23.18 | 121.26 | -4.02 | 12.44 | 0.3006 | -1364.3 | -423.6 | |
| 0.00 | 0.96 | 0.00 | 0.50 | 23.82 | 118.84 | -6.44 | 18.69 | 0.3215 | -618.0 | -503.5 | |
| 0.00 | 1.66 | 0.00 | 0.87 | 22.50 | 116.65 | -8.63 | 26.20 | 0.3155 | 837.0 | 645.9 | |
| 0.00 | 1.31 | 0.00 | 0.69 | 23.96 | 116.03 | -9.26 | 25.63 | 0.3413 | 863.0 | 590.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
