SDO HMI 2011-10-10 15:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 127.66 | 421.49 | 67.96 | 224.69 | -14.60 | 117.77 | -5.31 | 166.05 | 0.3697 | 307.1 | -6.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-10 15:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.42 | 108.57 | 9.22 | 57.56 | -14.30 | 121.04 | -2.05 | 174.35 | 0.3534 | 1192.4 | 354.3 | |
| 2.01 | 3.68 | 1.06 | 1.93 | -13.15 | 120.98 | -2.10 | 173.85 | 0.3347 | -741.8 | -532.6 | |
| 2.01 | -1.00 | 1.06 | -1.00 | -13.89 | 120.79 | -2.29 | 173.55 | 0.3470 | 843.8 | 999999 | |
| 15.67 | -1.00 | 8.31 | -1.00 | -14.65 | 120.66 | -2.42 | 173.44 | 0.3598 | 1092.5 | 999999 | |
| 1.49 | -1.00 | 0.79 | -1.00 | -14.91 | 120.32 | -2.77 | 172.62 | 0.3646 | 719.7 | 999999 | |
| 0.00 | 1.40 | 0.00 | 0.74 | -13.66 | 120.33 | -2.75 | 172.18 | 0.3444 | 910.0 | 742.6 | |
| 0.44 | 2.10 | 0.23 | 1.12 | -14.62 | 120.10 | -2.98 | 171.94 | 0.3604 | 1137.2 | 941.1 | |
| 0.00 | 1.58 | 0.00 | 0.84 | -15.17 | 120.06 | -3.02 | 172.06 | 0.3693 | 813.0 | 604.2 | |
| 0.00 | 0.88 | 0.00 | 0.47 | -15.39 | 120.03 | -3.05 | 172.05 | 0.3731 | 427.0 | 398.8 | |
| 0.00 | 1.05 | 0.00 | 0.55 | -13.63 | 120.02 | -3.06 | 171.30 | 0.3446 | 928.0 | 750.6 | |
| 0.00 | 2.63 | 0.00 | 1.40 | -14.79 | 119.88 | -3.20 | 171.43 | 0.3636 | 944.0 | 727.7 | |
| 4.99 | 5.95 | 2.64 | 3.15 | -14.27 | 119.86 | -3.22 | 171.14 | 0.3554 | 973.9 | 900.7 | |
| 0.00 | 0.96 | 0.00 | 0.51 | -15.01 | 119.79 | -3.30 | 171.27 | 0.3674 | 714.0 | 534.9 | |
| 0.00 | 2.28 | 0.00 | 1.21 | -14.66 | 119.67 | -3.41 | 170.80 | 0.3621 | 733.0 | 684.1 | |
| 0.00 | 2.63 | 0.00 | 1.40 | -14.76 | 119.48 | -3.60 | 170.35 | 0.3641 | 724.0 | 691.0 | |
| 0.00 | 1.14 | 0.00 | 0.61 | -15.43 | 119.25 | -3.83 | 170.08 | 0.3756 | 759.0 | 594.7 | |
| 0.00 | 0.79 | 0.00 | 0.42 | -13.29 | 119.07 | -4.01 | 168.46 | 0.3418 | 1014.0 | 750.2 | |
| 0.00 | 3.50 | 0.00 | 1.85 | -13.77 | 118.91 | -4.17 | 168.30 | 0.3500 | 959.0 | 704.8 | |
| 42.90 | 134.57 | 22.83 | 71.65 | -14.73 | 118.40 | -4.69 | 167.52 | 0.3671 | 1113.8 | 270.2 | |
| 0.00 | 0.96 | 0.00 | 0.52 | -15.64 | 117.38 | -5.71 | 165.55 | 0.3853 | -537.0 | -529.0 | |
| 0.00 | 0.61 | 0.00 | 0.33 | -13.98 | 117.39 | -5.69 | 164.38 | 0.3591 | 706.0 | 607.1 | |
| 3.33 | -19.00 | 1.77 | -19.00 | -14.27 | 117.20 | -5.89 | 164.11 | 0.3645 | -445.9 | 999999 | |
| 0.00 | 2.89 | 0.00 | 1.53 | -13.73 | 117.03 | -6.06 | 163.23 | 0.3569 | 816.0 | 530.8 | |
| 0.00 | 1.58 | 0.00 | 0.84 | -15.26 | 116.73 | -6.35 | 163.72 | 0.3822 | -540.0 | -316.2 | |
| 0.00 | 5.25 | 0.00 | 2.80 | -14.24 | 116.42 | -6.66 | 162.12 | 0.3678 | -779.0 | -765.4 | |
| 0.00 | 2.36 | 0.00 | 1.26 | -13.99 | 116.34 | -6.75 | 161.68 | 0.3643 | -1042.0 | -856.4 | |
| 12.61 | 42.20 | 6.72 | 22.51 | -14.25 | 115.71 | -7.38 | 160.35 | 0.3717 | -1134.0 | -684.9 | |
| 0.00 | 2.54 | 0.00 | 1.37 | -16.02 | 115.45 | -7.63 | 161.32 | 0.4000 | -871.0 | -588.0 | |
| 2.80 | -27.00 | 1.50 | -27.00 | -14.42 | 115.39 | -7.69 | 159.73 | 0.3760 | -789.6 | 999999 | |
| 0.00 | 3.33 | 0.00 | 1.79 | -15.03 | 115.24 | -7.84 | 159.95 | 0.3860 | -591.0 | -718.0 | |
| 0.00 | 2.89 | 0.00 | 1.57 | -16.97 | 115.01 | -8.08 | 161.10 | 0.4166 | -681.0 | -598.7 | |
| 0.00 | 0.96 | 0.00 | 0.52 | -15.10 | 114.96 | -8.13 | 159.35 | 0.3887 | -816.0 | -657.0 | |
| 0.00 | 2.54 | 0.00 | 1.35 | -14.01 | 114.87 | -8.21 | 158.08 | 0.3728 | -896.0 | -681.7 | |
| 1.93 | 7.00 | 1.04 | 3.80 | -16.33 | 114.72 | -8.36 | 159.92 | 0.4085 | -931.7 | -724.1 | |
| 8.41 | 20.75 | 4.53 | 11.18 | -15.26 | 114.54 | -8.54 | 158.56 | 0.3936 | -1014.0 | -613.2 | |
| 0.00 | 1.58 | 0.00 | 0.85 | -14.92 | 114.31 | -8.78 | 157.67 | 0.3898 | -786.0 | -613.2 | |
| 0.00 | 3.06 | 0.00 | 1.64 | -14.09 | 113.81 | -9.27 | 155.65 | 0.3808 | -913.0 | -842.8 | |
| 1.49 | 45.00 | 0.80 | 24.18 | -14.36 | 113.42 | -9.66 | 155.06 | 0.3872 | -1017.6 | -507.7 | |
| 0.00 | 1.40 | 0.00 | 0.76 | -15.61 | 113.33 | -9.75 | 156.21 | 0.4061 | -872.0 | -722.5 | |
| 0.00 | 0.88 | 0.00 | 0.48 | -15.94 | 113.13 | -9.96 | 156.10 | 0.4121 | -884.0 | -669.9 | |
| 10.16 | -38.00 | 5.46 | -38.00 | -14.39 | 113.08 | -10.01 | 154.32 | 0.3902 | -962.2 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
