SDO HMI 2011-10-10 16:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 107.78 | 431.00 | 57.35 | 229.54 | -14.62 | 117.73 | -4.80 | 167.36 | 0.3680 | 270.4 | 17.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-10 16:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.80 | 106.02 | 7.83 | 56.19 | -14.30 | 121.04 | -1.49 | 175.88 | 0.3526 | 1223.0 | 383.1 | |
| 1.66 | 3.33 | 0.87 | 1.75 | -13.06 | 120.93 | -1.61 | 175.27 | 0.3323 | -762.5 | -680.7 | |
| 15.32 | -1.00 | 8.12 | -1.00 | -14.59 | 120.64 | -1.90 | 174.84 | 0.3578 | 1142.4 | 999999 | |
| 0.00 | 1.05 | 0.00 | 0.55 | -13.66 | 120.34 | -2.20 | 173.74 | 0.3432 | 977.0 | 723.4 | |
| 1.93 | 2.71 | 1.02 | 1.44 | -14.59 | 120.08 | -2.45 | 173.34 | 0.3588 | 933.5 | 824.0 | |
| 0.79 | 1.49 | 0.42 | 0.79 | -15.17 | 120.04 | -2.49 | 173.43 | 0.3682 | 753.9 | 676.9 | |
| 0.00 | 1.05 | 0.00 | 0.55 | -13.63 | 119.97 | -2.57 | 172.69 | 0.3434 | 905.0 | 645.7 | |
| 4.64 | 5.60 | 2.46 | 2.97 | -14.24 | 119.90 | -2.63 | 172.73 | 0.3534 | 990.1 | 890.3 | |
| 0.00 | 2.01 | 0.00 | 1.07 | -14.78 | 119.83 | -2.70 | 172.74 | 0.3624 | 890.0 | 748.8 | |
| 0.00 | 1.40 | 0.00 | 0.75 | -15.01 | 119.76 | -2.77 | 172.65 | 0.3662 | 728.0 | 489.7 | |
| 0.00 | 4.46 | 0.00 | 2.37 | -14.66 | 119.52 | -3.01 | 171.87 | 0.3610 | 903.0 | 768.8 | |
| 0.00 | 0.70 | 0.00 | 0.37 | -15.46 | 119.42 | -3.12 | 171.92 | 0.3742 | 733.0 | 508.2 | |
| 0.00 | 1.14 | 0.00 | 0.61 | -15.46 | 119.23 | -3.30 | 171.44 | 0.3747 | 694.0 | 583.7 | |
| 0.00 | 2.10 | 0.00 | 1.11 | -13.38 | 119.11 | -3.42 | 170.16 | 0.3415 | 991.0 | 803.5 | |
| 0.00 | 2.45 | 0.00 | 1.29 | -13.73 | 118.92 | -3.62 | 169.81 | 0.3477 | 1072.0 | 887.4 | |
| 7.79 | 141.39 | 4.14 | 75.22 | -14.53 | 118.75 | -3.78 | 169.77 | 0.3611 | 1335.8 | 371.0 | |
| 0.44 | -16.00 | 0.23 | -16.00 | -14.28 | 118.48 | -4.06 | 168.90 | 0.3578 | 1040.8 | 999999 | |
| 17.07 | -16.00 | 9.09 | -16.00 | -14.82 | 118.37 | -4.16 | 168.93 | 0.3669 | 1187.8 | 999999 | |
| 4.46 | -16.00 | 2.37 | -16.00 | -14.50 | 118.38 | -4.15 | 168.77 | 0.3617 | 1173.6 | 999999 | |
| 0.00 | 1.49 | 0.00 | 0.80 | -15.57 | 118.11 | -4.42 | 168.66 | 0.3795 | 627.0 | 458.1 | |
| 0.00 | 0.88 | 0.00 | 0.46 | -13.99 | 118.11 | -4.42 | 167.76 | 0.3545 | 810.0 | 626.8 | |
| 5.52 | -16.00 | 2.95 | -16.00 | -15.21 | 117.74 | -4.79 | 167.54 | 0.3752 | 634.1 | 999999 | |
| 2.80 | -16.00 | 1.49 | -16.00 | -14.26 | 117.17 | -5.36 | 165.47 | 0.3622 | -461.1 | 999999 | |
| 0.00 | 1.23 | 0.00 | 0.65 | -12.99 | 117.20 | -5.33 | 164.58 | 0.3419 | 792.0 | 638.3 | |
| 1.23 | 5.69 | 0.65 | 3.01 | -13.72 | 117.06 | -5.47 | 164.78 | 0.3541 | 697.3 | 432.7 | |
| 0.00 | 2.45 | 0.00 | 1.31 | -15.26 | 116.71 | -5.82 | 165.01 | 0.3798 | -625.0 | -421.9 | |
| 0.00 | 3.24 | 0.00 | 1.72 | -14.27 | 116.52 | -6.01 | 163.79 | 0.3651 | -756.0 | -728.3 | |
| 0.00 | 3.59 | 0.00 | 1.91 | -14.01 | 116.37 | -6.16 | 163.21 | 0.3618 | -858.0 | -790.5 | |
| 0.00 | 1.58 | 0.00 | 0.84 | -14.24 | 116.37 | -6.16 | 163.38 | 0.3653 | -983.0 | -761.9 | |
| 7.44 | 37.38 | 3.96 | 19.90 | -14.15 | 115.69 | -6.84 | 161.58 | 0.3673 | -1211.5 | -876.7 | |
| 0.00 | 1.66 | 0.00 | 0.90 | -16.37 | 115.61 | -6.92 | 163.21 | 0.4018 | -748.0 | -526.4 | |
| 0.00 | 1.05 | 0.00 | 0.57 | -16.15 | 115.40 | -7.13 | 162.55 | 0.3994 | -849.0 | -671.6 | |
| 3.24 | -30.00 | 1.73 | -30.00 | -14.38 | 115.37 | -7.16 | 160.99 | 0.3725 | -881.8 | 999999 | |
| 0.00 | 2.45 | 0.00 | 1.32 | -15.92 | 115.32 | -7.22 | 162.18 | 0.3964 | -569.0 | -611.1 | |
| 0.00 | 2.54 | 0.00 | 1.36 | -15.02 | 115.25 | -7.28 | 161.28 | 0.3829 | -916.0 | -695.8 | |
| 0.00 | 2.89 | 0.00 | 1.57 | -16.96 | 115.02 | -7.51 | 162.34 | 0.4136 | -647.0 | -508.5 | |
| 0.00 | 1.93 | 0.00 | 1.03 | -14.00 | 114.88 | -7.65 | 159.44 | 0.3694 | -896.0 | -719.4 | |
| 0.00 | 1.58 | 0.00 | 0.86 | -16.74 | 114.78 | -7.75 | 161.62 | 0.4114 | -728.0 | -484.1 | |
| 0.00 | 6.04 | 0.00 | 3.27 | -16.35 | 114.67 | -7.86 | 161.06 | 0.4061 | -974.0 | -809.9 | |
| 11.12 | 24.69 | 5.98 | 13.28 | -15.29 | 114.46 | -8.07 | 159.66 | 0.3912 | -952.3 | -545.2 | |
| 0.00 | 0.96 | 0.00 | 0.52 | -16.19 | 114.30 | -8.23 | 160.10 | 0.4058 | -673.0 | -508.9 | |
| 0.00 | 1.75 | 0.00 | 0.94 | -15.62 | 114.07 | -8.46 | 159.07 | 0.3984 | -771.0 | -565.9 | |
| 0.00 | 3.50 | 0.00 | 1.87 | -14.05 | 113.82 | -8.71 | 156.93 | 0.3765 | -948.0 | -768.2 | |
| 0.00 | 6.48 | 0.00 | 3.47 | -14.38 | 113.50 | -9.03 | 156.52 | 0.3834 | -847.0 | -901.0 | |
| 0.00 | 1.23 | 0.00 | 0.66 | -15.69 | 113.31 | -9.22 | 157.46 | 0.4040 | -870.0 | -664.4 | |
| 0.00 | 1.14 | 0.00 | 0.62 | -15.96 | 113.08 | -9.45 | 157.21 | 0.4093 | -705.0 | -599.2 | |
| 7.53 | 36.68 | 4.04 | 19.67 | -14.38 | 113.12 | -9.41 | 155.66 | 0.3859 | -1053.3 | -506.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
