SDO HMI 2011-10-10 16:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 61.54 | 154.80 | 32.06 | 80.60 | 19.94 | 111.00 | -11.53 | 37.92 | 0.3065 | 97.3 | 2.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-10 16:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.45 | 0.00 | 1.26 | 19.70 | 115.48 | -7.05 | 26.26 | 0.2623 | 825.0 | 712.5 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 21.98 | 113.19 | -9.34 | 28.84 | 0.3134 | 764.0 | 628.1 | |
| 7.70 | 83.26 | 3.99 | 43.20 | 20.14 | 112.43 | -10.10 | 34.17 | 0.2944 | -1049.0 | -272.8 | |
| 19.70 | -3.00 | 10.21 | -3.00 | 19.92 | 112.06 | -10.47 | 35.58 | 0.2950 | -1148.2 | 999999 | |
| 0.00 | 1.84 | 0.00 | 0.97 | 22.61 | 111.70 | -10.83 | 31.40 | 0.3345 | 846.0 | 694.3 | |
| 3.06 | -3.00 | 1.59 | -3.00 | 19.70 | 111.69 | -10.85 | 36.99 | 0.2958 | -868.9 | 999999 | |
| 0.00 | 0.88 | 0.00 | 0.46 | 20.64 | 111.16 | -11.37 | 36.27 | 0.3132 | 482.0 | 421.0 | |
| 0.00 | 0.88 | 0.00 | 0.46 | 20.69 | 110.67 | -11.86 | 37.30 | 0.3188 | -722.0 | -460.8 | |
| 0.00 | 3.59 | 0.00 | 1.87 | 19.83 | 110.57 | -11.96 | 39.34 | 0.3089 | 909.0 | 594.4 | |
| 0.00 | 1.93 | 0.00 | 1.01 | 20.25 | 110.38 | -12.15 | 38.86 | 0.3162 | 15.0 | 46.1 | |
| 0.00 | 3.41 | 0.00 | 1.77 | 18.96 | 110.44 | -12.09 | 41.58 | 0.2997 | -1004.0 | -835.8 | |
| 0.00 | 0.79 | 0.00 | 0.41 | 19.67 | 110.36 | -12.17 | 40.17 | 0.3092 | 733.0 | 504.7 | |
| 0.00 | 1.58 | 0.00 | 0.82 | 20.10 | 110.13 | -12.40 | 39.75 | 0.3168 | 858.0 | 546.3 | |
| 0.00 | 2.54 | 0.00 | 1.33 | 19.94 | 109.95 | -12.59 | 40.49 | 0.3169 | 504.0 | 443.4 | |
| 0.00 | 1.75 | 0.00 | 0.91 | 19.44 | 109.63 | -12.90 | 42.28 | 0.3144 | 918.0 | 664.9 | |
| 31.08 | 48.85 | 16.27 | 25.58 | 19.85 | 109.07 | -13.46 | 42.51 | 0.3255 | 1011.0 | 446.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
