SDO HMI 2011-10-10 17:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.13 | 181.65 | 19.58 | 110.33 | 23.37 | 154.09 | 32.11 | 302.53 | 0.5808 | -589.6 | -309.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-10 17:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.95 | 169.75 | 3.64 | 103.41 | 23.06 | 154.77 | 32.79 | 301.55 | 0.5869 | -867.8 | -377.3 | |
| 26.18 | -1.00 | 15.94 | -1.00 | 23.30 | 154.41 | 32.43 | 302.15 | 0.5839 | -1211.8 | 999999 | |
| 0.00 | 1.31 | 0.00 | 0.78 | 21.86 | 153.27 | 31.29 | 300.55 | 0.5618 | 563.0 | 402.6 | |
| 0.00 | 0.96 | 0.00 | 0.58 | 21.99 | 153.22 | 31.24 | 300.79 | 0.5620 | 522.0 | 356.5 | |
| 0.00 | 1.31 | 0.00 | 0.77 | 25.80 | 148.24 | 26.26 | 310.94 | 0.5295 | 648.0 | 503.6 | |
| 0.00 | 1.49 | 0.00 | 0.85 | 23.77 | 147.60 | 25.62 | 308.21 | 0.5057 | 134.0 | 195.7 | |
| 0.00 | 2.28 | 0.00 | 1.32 | 25.75 | 147.97 | 25.99 | 311.11 | 0.5260 | 716.0 | 625.2 | |
| 0.00 | 0.96 | 0.00 | 0.56 | 26.94 | 147.92 | 25.94 | 313.01 | 0.5355 | 626.0 | 497.5 | |
| 0.00 | 1.05 | 0.00 | 0.61 | 26.31 | 147.62 | 25.64 | 312.33 | 0.5268 | 724.0 | 635.9 | |
| 0.00 | 1.23 | 0.00 | 0.70 | 25.79 | 144.80 | 22.82 | 314.48 | 0.4914 | 917.0 | 787.6 | |
| 0.00 | 1.31 | 0.00 | 0.75 | 26.85 | 144.62 | 22.64 | 316.36 | 0.4997 | 773.0 | 622.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
