SDO HMI 2011-10-11 08:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 100.92 | 535.48 | 90.83 | 481.22 | 26.73 | 58.38 | -55.36 | 61.85 | 0.8352 | -678.2 | -183.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-11 08:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.05 | 0.00 | 0.90 | 25.72 | 60.34 | -53.39 | 62.66 | 0.8164 | 93.0 | 154.2 | |
| 89.79 | 524.01 | 80.04 | 468.32 | 26.91 | 58.65 | -55.08 | 61.60 | 0.8334 | -836.9 | -195.9 | |
| 0.00 | 0.79 | 0.00 | 0.76 | 29.45 | 56.17 | -57.57 | 59.16 | 0.8581 | -417.0 | -342.0 | |
| 0.79 | -2.00 | 0.72 | -2.00 | 27.41 | 57.50 | -56.23 | 61.25 | 0.8439 | -182.6 | 999999 | |
| 1.84 | -2.00 | 1.65 | -2.00 | 26.18 | 58.12 | -55.61 | 62.57 | 0.8365 | -306.5 | 999999 | |
| 0.96 | -2.00 | 0.88 | -2.00 | 26.34 | 57.65 | -56.09 | 62.48 | 0.8408 | -351.3 | 999999 | |
| 5.26 | -2.00 | 4.66 | -2.00 | 24.97 | 58.44 | -55.30 | 63.94 | 0.8318 | 418.0 | 999999 | |
| 0.00 | 1.31 | 0.00 | 1.22 | 26.75 | 56.78 | -56.95 | 62.15 | 0.8486 | 309.0 | 153.3 | |
| 0.00 | 1.40 | 0.00 | 1.29 | 24.73 | 56.75 | -56.98 | 64.52 | 0.8458 | 504.0 | 383.4 | |
| 2.28 | 6.92 | 2.88 | 8.73 | 23.61 | 46.26 | -67.47 | 66.92 | 0.9217 | 412.9 | 430.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
