SDO HMI 2011-10-11 10:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 108.77 | 546.11 | 95.97 | 479.00 | 26.86 | 58.31 | -54.33 | 61.47 | 0.8268 | -672.8 | -166.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-11 10:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 99.40 | 537.44 | 86.59 | 468.75 | 26.96 | 58.59 | -54.05 | 61.32 | 0.8247 | -761.0 | -174.1 | |
| 0.00 | 1.05 | 0.00 | 0.98 | 29.54 | 56.16 | -56.48 | 58.83 | 0.8498 | -322.0 | -253.8 | |
| 2.89 | -1.00 | 2.53 | -1.00 | 26.10 | 58.15 | -54.49 | 62.43 | 0.8268 | -326.6 | 999999 | |
| 3.15 | -1.00 | 2.80 | -1.00 | 26.42 | 57.69 | -54.95 | 62.14 | 0.8314 | -301.0 | 999999 | |
| 0.00 | 0.26 | 0.00 | 0.34 | 26.18 | 45.16 | -67.48 | 64.14 | 0.9229 | 198.0 | 279.3 | |
| 3.33 | 7.36 | 4.05 | 8.93 | 23.60 | 46.21 | -66.43 | 66.86 | 0.9151 | 439.2 | 428.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
