SDO HMI 2011-10-11 22:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 55.92 | 217.83 | 54.58 | 209.77 | -12.42 | 49.70 | -56.33 | 108.51 | 0.8586 | 192.4 | 62.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-11 22:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.72 | 150.09 | 28.51 | 139.73 | -12.24 | 50.98 | -55.05 | 108.67 | 0.8476 | 778.1 | 212.0 | |
| 0.00 | 0.96 | 0.00 | 0.93 | -14.12 | 50.01 | -56.02 | 110.49 | 0.8605 | -265.0 | -175.7 | |
| 0.00 | 0.35 | 0.00 | 0.34 | -14.00 | 50.00 | -56.03 | 110.35 | 0.8603 | -120.0 | -173.2 | |
| 1.14 | -1.00 | 1.07 | -1.00 | -12.51 | 50.41 | -55.62 | 108.80 | 0.8532 | 228.1 | 999999 | |
| 2.36 | -1.00 | 2.24 | -1.00 | -12.37 | 50.23 | -55.79 | 108.59 | 0.8544 | 205.3 | 999999 | |
| 4.90 | 12.43 | 4.79 | 12.18 | -13.88 | 49.54 | -56.49 | 110.07 | 0.8638 | 548.0 | 256.5 | |
| 0.00 | 2.89 | 0.00 | 2.80 | -12.29 | 49.43 | -56.60 | 108.26 | 0.8610 | -447.0 | -465.8 | |
| 0.00 | 2.98 | 0.00 | 2.90 | -12.47 | 49.14 | -56.89 | 108.38 | 0.8638 | -479.0 | -435.6 | |
| 0.00 | 0.96 | 0.00 | 0.98 | -14.49 | 48.38 | -57.65 | 110.40 | 0.8746 | -501.0 | -460.2 | |
| 0.00 | 0.79 | 0.00 | 0.78 | -11.66 | 48.44 | -57.58 | 107.27 | 0.8678 | -248.0 | -256.9 | |
| 2.10 | 3.76 | 2.08 | 3.73 | -11.51 | 48.38 | -57.65 | 107.09 | 0.8680 | -566.7 | -413.5 | |
| 0.00 | 1.66 | 0.00 | 1.75 | -14.08 | 47.07 | -58.96 | 109.56 | 0.8839 | -620.0 | -539.4 | |
| 1.23 | 4.99 | 1.23 | 5.00 | -11.40 | 47.95 | -58.07 | 106.84 | 0.8713 | -398.6 | -247.0 | |
| 0.00 | 1.05 | 0.00 | 1.12 | -14.05 | 46.72 | -59.31 | 109.43 | 0.8865 | -315.0 | -306.0 | |
| 0.00 | 1.23 | 0.00 | 1.26 | -11.44 | 47.18 | -58.85 | 106.68 | 0.8777 | -62.0 | -89.0 | |
| 0.00 | 2.01 | 0.00 | 2.11 | -11.99 | 46.62 | -59.41 | 107.14 | 0.8831 | -669.0 | -593.0 | |
| 10.76 | 22.14 | 11.69 | 24.06 | -13.10 | 45.76 | -60.27 | 108.14 | 0.8918 | -519.4 | -263.0 | |
| 0.00 | 7.79 | 0.00 | 8.24 | -11.81 | 46.26 | -59.77 | 106.85 | 0.8855 | -709.0 | -499.6 | |
| 0.00 | 1.75 | 0.00 | 1.86 | -11.51 | 46.12 | -59.90 | 106.48 | 0.8860 | -501.0 | -435.9 | |
| 1.40 | -17.00 | 1.54 | -17.00 | -13.04 | 45.47 | -60.55 | 107.99 | 0.8938 | 233.8 | 999999 | |
| 1.31 | -17.00 | 1.43 | -17.00 | -12.65 | 45.57 | -60.46 | 107.59 | 0.8924 | -268.3 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
