SDO HMI 2011-10-11 23:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.80 | 16.37 | 1.45 | 8.51 | 20.82 | 95.54 | -9.94 | 32.17 | 0.3034 | -96.3 | 68.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-11 23:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.05 | 0.00 | 0.54 | 19.71 | 97.59 | -7.88 | 28.71 | 0.2700 | -811.0 | -590.6 | |
| 1.49 | 2.36 | 0.77 | 1.22 | 19.81 | 96.53 | -8.95 | 31.61 | 0.2805 | -875.8 | -793.1 | |
| 0.00 | 1.05 | 0.00 | 0.54 | 21.05 | 96.42 | -9.05 | 29.59 | 0.2988 | 697.0 | 474.3 | |
| 1.31 | 2.01 | 0.68 | 1.04 | 20.86 | 96.27 | -9.20 | 30.32 | 0.2974 | 858.3 | 750.5 | |
| 0.00 | 1.40 | 0.00 | 0.72 | 19.90 | 96.23 | -9.24 | 32.25 | 0.2843 | -634.0 | -407.1 | |
| 0.00 | 1.84 | 0.00 | 0.96 | 21.10 | 95.77 | -9.71 | 31.20 | 0.3050 | -995.0 | -669.6 | |
| 0.00 | 1.58 | 0.00 | 0.82 | 20.79 | 95.79 | -9.69 | 31.72 | 0.3005 | -900.0 | -638.6 | |
| 0.00 | 3.50 | 0.00 | 1.84 | 21.68 | 93.93 | -11.55 | 34.55 | 0.3295 | 1025.0 | 808.4 | |
| 0.00 | 1.58 | 0.00 | 0.83 | 21.46 | 93.72 | -11.76 | 35.44 | 0.3286 | 895.0 | 729.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
