SDO HMI 2011-10-12 07:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 107.70 | 547.93 | 58.97 | 300.17 | 23.13 | 120.44 | 19.35 | 314.41 | 0.4286 | -1516.8 | -430.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-12 07:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.23 | 2.54 | 0.67 | 1.40 | 21.75 | 122.10 | 21.01 | 309.71 | 0.4347 | 689.1 | 388.9 | |
| 1.23 | 543.02 | 0.67 | 297.47 | 22.80 | 121.61 | 20.52 | 312.28 | 0.4385 | -548.7 | -432.4 | |
| 103.75 | -2.00 | 56.82 | -2.00 | 23.12 | 120.44 | 19.35 | 314.40 | 0.4284 | -1590.1 | 999999 | |
| 1.49 | -2.00 | 0.81 | -2.00 | 23.68 | 119.77 | 18.68 | 316.34 | 0.4267 | -1041.5 | 999999 | |
| 0.00 | 1.58 | 0.00 | 0.87 | 26.22 | 118.70 | 17.61 | 322.10 | 0.4437 | -645.0 | -540.1 | |
| 0.00 | 0.79 | 0.00 | 0.43 | 25.53 | 118.38 | 17.29 | 321.49 | 0.4326 | -735.0 | -590.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
