SDO HMI 2011-10-12 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 85.84 | 378.54 | 48.16 | 213.69 | -14.64 | 118.71 | 19.81 | 223.11 | 0.4807 | 300.5 | 231.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-12 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.91 | 41.39 | 3.95 | 23.68 | -13.78 | 121.30 | 22.40 | 228.11 | 0.4991 | 869.2 | 196.2 | |
| 4.20 | -1.00 | 2.40 | -1.00 | -14.09 | 121.09 | 22.20 | 227.39 | 0.4999 | 877.8 | 999999 | |
| 0.00 | 1.23 | 0.00 | 0.70 | -13.73 | 120.86 | 21.96 | 227.63 | 0.4937 | 803.0 | 642.5 | |
| 0.00 | 5.78 | 0.00 | 3.30 | -14.37 | 120.79 | 21.89 | 226.58 | 0.4993 | 613.0 | 543.2 | |
| 1.14 | 219.21 | 0.65 | 124.61 | -14.39 | 120.49 | 21.59 | 226.16 | 0.4962 | 888.6 | 433.4 | |
| 0.00 | 1.58 | 0.00 | 0.90 | -15.42 | 120.60 | 21.70 | 224.80 | 0.5080 | -172.0 | -142.8 | |
| 0.00 | 3.15 | 0.00 | 1.78 | -13.74 | 120.26 | 21.36 | 226.84 | 0.4871 | 949.0 | 795.1 | |
| 1.40 | -5.00 | 0.80 | -5.00 | -14.38 | 120.29 | 21.39 | 225.91 | 0.4940 | 730.1 | 999999 | |
| 0.00 | 1.49 | 0.00 | 0.84 | -13.42 | 120.10 | 21.20 | 227.12 | 0.4820 | 949.0 | 809.9 | |
| 2.01 | 4.38 | 1.13 | 2.46 | -13.16 | 120.01 | 21.11 | 227.40 | 0.4784 | 938.9 | 776.3 | |
| 0.96 | 1.93 | 0.54 | 1.09 | -13.63 | 119.92 | 21.02 | 226.55 | 0.4822 | 926.0 | 870.8 | |
| 0.00 | 4.55 | 0.00 | 2.62 | -16.23 | 120.06 | 21.16 | 222.93 | 0.5109 | 733.0 | 673.2 | |
| 0.96 | -5.00 | 0.55 | -5.00 | -14.30 | 119.82 | 20.92 | 225.40 | 0.4880 | 945.4 | 999999 | |
| 0.00 | 1.49 | 0.00 | 0.86 | -17.40 | 120.13 | 21.23 | 221.44 | 0.5242 | -638.0 | -395.7 | |
| 34.30 | -5.00 | 19.51 | -5.00 | -14.87 | 119.78 | 20.88 | 224.49 | 0.4935 | 1167.4 | 999999 | |
| 0.00 | 1.23 | 0.00 | 0.69 | -13.97 | 119.62 | 20.72 | 225.62 | 0.4824 | 933.0 | 748.6 | |
| 1.05 | -5.00 | 0.59 | -5.00 | -14.22 | 119.61 | 20.72 | 225.22 | 0.4850 | 1051.5 | 999999 | |
| 0.00 | 1.58 | 0.00 | 0.88 | -11.81 | 119.40 | 20.50 | 228.77 | 0.4578 | 523.0 | 410.5 | |
| 1.23 | -5.00 | 0.69 | -5.00 | -14.51 | 119.44 | 20.54 | 224.57 | 0.4861 | 1251.4 | 999999 | |
| 2.28 | -5.00 | 1.29 | -5.00 | -14.89 | 119.38 | 20.48 | 223.92 | 0.4895 | 1113.7 | 999999 | |
| 1.49 | 1.75 | 0.85 | 1.00 | -16.10 | 119.18 | 20.28 | 221.91 | 0.5006 | 580.3 | 503.7 | |
| 3.41 | 8.40 | 1.89 | 4.66 | -14.21 | 116.44 | 17.54 | 220.53 | 0.4515 | -917.2 | -729.6 | |
| 0.00 | 11.38 | 0.00 | 6.33 | -14.74 | 116.29 | 17.39 | 219.50 | 0.4563 | -621.0 | -637.6 | |
| 0.00 | 1.40 | 0.00 | 0.78 | -15.02 | 116.02 | 17.12 | 218.67 | 0.4570 | -590.0 | -526.8 | |
| 0.00 | 2.80 | 0.00 | 1.55 | -14.76 | 115.84 | 16.94 | 218.74 | 0.4521 | -879.0 | -738.6 | |
| 0.00 | 1.49 | 0.00 | 0.84 | -17.44 | 115.98 | 17.08 | 215.39 | 0.4859 | -818.0 | -655.8 | |
| 0.00 | 1.40 | 0.00 | 0.78 | -15.23 | 115.52 | 16.62 | 217.56 | 0.4547 | -516.0 | -444.9 | |
| 0.00 | 0.70 | 0.00 | 0.39 | -15.28 | 115.11 | 16.21 | 216.79 | 0.4514 | -756.0 | -651.1 | |
| 0.00 | 1.05 | 0.00 | 0.59 | -16.41 | 114.97 | 16.07 | 215.07 | 0.4641 | -595.0 | -434.9 | |
| 0.00 | 0.61 | 0.00 | 0.34 | -14.73 | 114.84 | 15.94 | 217.10 | 0.4421 | -946.0 | -795.9 | |
| 0.00 | 1.14 | 0.00 | 0.63 | -15.72 | 114.82 | 15.92 | 215.71 | 0.4543 | -705.0 | -590.0 | |
| 0.00 | 1.23 | 0.00 | 0.68 | -16.04 | 114.68 | 15.78 | 215.06 | 0.4570 | -696.0 | -561.2 | |
| 0.00 | 0.88 | 0.00 | 0.48 | -14.98 | 114.57 | 15.67 | 216.29 | 0.4427 | -869.0 | -714.3 | |
| 2.89 | 6.74 | 1.60 | 3.74 | -15.84 | 114.50 | 15.61 | 215.01 | 0.4529 | -1008.2 | -790.3 | |
| 0.00 | 0.70 | 0.00 | 0.39 | -18.08 | 114.21 | 15.31 | 211.76 | 0.4788 | -635.0 | -498.0 | |
| 0.00 | 1.93 | 0.00 | 1.06 | -15.44 | 113.83 | 14.93 | 214.37 | 0.4418 | -770.0 | -622.6 | |
| 0.00 | 0.96 | 0.00 | 0.53 | -16.05 | 113.87 | 14.98 | 213.65 | 0.4500 | -656.0 | -580.3 | |
| 0.00 | 0.88 | 0.00 | 0.49 | -16.30 | 113.60 | 14.71 | 212.86 | 0.4510 | -784.0 | -674.0 | |
| 0.00 | 2.10 | 0.00 | 1.16 | -16.01 | 113.52 | 14.62 | 213.07 | 0.4464 | -929.0 | -758.0 | |
| 0.00 | 2.01 | 0.00 | 1.12 | -16.55 | 113.43 | 14.53 | 212.23 | 0.4528 | -641.0 | -492.4 | |
| 13.21 | 22.49 | 7.14 | 12.15 | -12.74 | 113.08 | 14.18 | 216.81 | 0.4005 | 1036.5 | 610.0 | |
| 0.00 | 1.14 | 0.00 | 0.63 | -15.93 | 113.22 | 14.32 | 212.63 | 0.4430 | -681.0 | -611.2 | |
| 0.00 | 1.05 | 0.00 | 0.57 | -14.70 | 112.85 | 13.95 | 213.55 | 0.4237 | -979.0 | -794.1 | |
| 0.00 | 1.14 | 0.00 | 0.63 | -16.80 | 112.97 | 14.07 | 211.11 | 0.4523 | -785.0 | -605.2 | |
| 2.19 | -41.00 | 1.18 | -41.00 | -12.92 | 112.68 | 13.78 | 215.76 | 0.3990 | 835.3 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.43 | -15.18 | 112.75 | 13.85 | 212.74 | 0.4292 | -829.0 | -735.0 | |
| 6.21 | 10.50 | 3.40 | 5.75 | -15.11 | 112.40 | 13.50 | 212.16 | 0.4252 | -994.2 | -690.4 | |
| 0.00 | 1.58 | 0.00 | 0.86 | -15.62 | 112.18 | 13.28 | 211.09 | 0.4301 | -765.0 | -566.1 | |
| 0.00 | 1.31 | 0.00 | 0.72 | -15.77 | 111.68 | 12.78 | 209.95 | 0.4281 | -788.0 | -610.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
