SDO HMI 2011-10-12 20:59:47 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 92.61 | 519.50 | 53.24 | 298.71 | 23.11 | 120.19 | 26.26 | 306.68 | 0.5096 | -1334.8 | -425.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-12 20:59:47 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.96 | 0.00 | 0.54 | 25.58 | 114.96 | 21.03 | 316.43 | 0.4716 | 838.0 | 669.9 | |
| 0.00 | 0.87 | 0.00 | 0.50 | 25.47 | 118.17 | 24.24 | 312.58 | 0.5054 | -684.0 | -586.4 | |
| 1.75 | 514.62 | 1.00 | 295.90 | 23.84 | 119.57 | 25.64 | 308.50 | 0.5078 | -865.0 | -432.3 | |
| 90.86 | -3.00 | 52.24 | -3.00 | 23.10 | 120.21 | 26.28 | 306.64 | 0.5097 | -1490.5 | 999999 | |
| 0.00 | 1.31 | 0.00 | 0.75 | 21.32 | 121.22 | 27.29 | 302.68 | 0.5095 | 835.0 | 625.3 | |
| 0.00 | 0.87 | 0.00 | 0.51 | 22.04 | 121.65 | 27.72 | 303.60 | 0.5198 | -665.0 | -489.0 | |
| 0.00 | 0.87 | 0.00 | 0.51 | 21.60 | 122.02 | 28.09 | 302.54 | 0.5214 | 665.0 | 514.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
