SDO HMI 2011-10-13 04:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.19 | 27.49 | 1.18 | 14.85 | 19.74 | 109.30 | 19.76 | 307.37 | 0.4019 | 180.1 | 502.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-13 04:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.23 | 0.00 | 0.68 | 20.84 | 112.72 | 23.18 | 305.60 | 0.4544 | -793.0 | -635.0 | |
| 0.00 | 1.23 | 0.00 | 0.67 | 20.57 | 110.78 | 21.24 | 307.22 | 0.4278 | -964.0 | -782.3 | |
| 0.00 | 0.96 | 0.00 | 0.53 | 20.73 | 110.70 | 21.16 | 307.63 | 0.4281 | -879.0 | -723.4 | |
| 0.00 | 1.49 | 0.00 | 0.81 | 19.87 | 110.37 | 20.84 | 306.29 | 0.4168 | -937.0 | -677.7 | |
| 0.00 | 2.19 | 0.00 | 1.18 | 19.40 | 109.83 | 20.30 | 305.95 | 0.4059 | 733.0 | 488.7 | |
| 2.19 | 4.99 | 1.18 | 2.69 | 19.39 | 109.29 | 19.75 | 306.60 | 0.3988 | 902.0 | 753.2 | |
| 0.00 | 1.49 | 0.00 | 0.80 | 19.62 | 108.95 | 19.41 | 307.52 | 0.3964 | 808.0 | 618.1 | |
| 0.00 | 2.71 | 0.00 | 1.47 | 20.23 | 108.93 | 19.39 | 308.85 | 0.4017 | 897.0 | 731.2 | |
| 0.00 | 1.31 | 0.00 | 0.71 | 19.53 | 108.81 | 19.27 | 307.53 | 0.3938 | 771.0 | 588.5 | |
| 0.00 | 9.89 | 0.00 | 5.31 | 19.54 | 108.47 | 18.93 | 308.00 | 0.3897 | 1133.0 | 952.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
