SDO HMI 2011-10-13 09:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 135.57 | 760.99 | 90.74 | 509.01 | -12.34 | 48.61 | -38.19 | 115.95 | 0.6731 | -39.8 | -13.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-13 09:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 37.36 | 240.84 | 23.68 | 152.65 | -11.72 | 52.32 | -34.48 | 117.33 | 0.6263 | 1067.2 | 404.9 | |
| 5.77 | -1.00 | 3.69 | -1.00 | -11.91 | 51.84 | -34.96 | 117.28 | 0.6331 | 751.2 | 999999 | |
| 0.00 | 3.76 | 0.00 | 2.42 | -12.10 | 51.25 | -35.55 | 117.17 | 0.6413 | 689.0 | 521.8 | |
| 0.79 | 100.69 | 0.51 | 66.04 | -12.20 | 50.74 | -36.06 | 116.98 | 0.6479 | 900.8 | 324.2 | |
| 1.22 | -4.00 | 0.80 | -4.00 | -12.55 | 50.65 | -36.15 | 117.41 | 0.6510 | 706.2 | 999999 | |
| 6.30 | -4.00 | 4.11 | -4.00 | -12.41 | 50.44 | -36.36 | 117.08 | 0.6526 | 917.8 | 999999 | |
| 2.27 | -4.00 | 1.49 | -4.00 | -12.67 | 50.25 | -36.55 | 117.32 | 0.6563 | 755.8 | 999999 | |
| 0.96 | -4.00 | 0.63 | -4.00 | -12.86 | 50.22 | -36.59 | 117.56 | 0.6578 | 846.5 | 999999 | |
| 0.00 | 0.87 | 0.00 | 0.57 | -11.82 | 50.27 | -36.53 | 116.15 | 0.6514 | 414.0 | 345.1 | |
| 0.00 | 2.36 | 0.00 | 1.57 | -14.28 | 49.76 | -37.04 | 119.20 | 0.6711 | 568.0 | 474.5 | |
| 0.00 | 0.52 | 0.00 | 0.35 | -13.42 | 49.93 | -36.88 | 118.14 | 0.6643 | 445.0 | 380.0 | |
| 5.51 | -4.00 | 3.63 | -4.00 | -12.98 | 49.89 | -36.91 | 117.51 | 0.6622 | 712.3 | 999999 | |
| 0.26 | -4.00 | 0.17 | -4.00 | -12.56 | 49.96 | -36.84 | 116.99 | 0.6591 | 350.0 | 999999 | |
| 1.66 | -4.00 | 1.10 | -4.00 | -13.34 | 49.63 | -37.17 | 117.85 | 0.6672 | 414.8 | 999999 | |
| 0.00 | 1.66 | 0.00 | 1.12 | -13.40 | 48.68 | -38.12 | 117.35 | 0.6784 | -734.0 | -525.1 | |
| 0.00 | 1.14 | 0.00 | 0.77 | -13.64 | 48.48 | -38.32 | 117.55 | 0.6819 | 125.0 | 180.8 | |
| 0.00 | 0.96 | 0.00 | 0.65 | -13.21 | 47.81 | -38.99 | 116.58 | 0.6872 | -681.0 | -584.2 | |
| 0.00 | 2.97 | 0.00 | 2.04 | -14.06 | 47.49 | -39.32 | 117.51 | 0.6953 | -723.0 | -628.6 | |
| 1.22 | 399.10 | 0.82 | 276.52 | -11.48 | 47.85 | -38.96 | 114.26 | 0.6782 | 395.4 | -321.4 | |
| 2.97 | -19.00 | 2.00 | -19.00 | -11.36 | 47.75 | -39.05 | 114.05 | 0.6787 | 673.4 | 999999 | |
| 0.00 | 1.66 | 0.00 | 1.15 | -13.95 | 47.19 | -39.61 | 117.20 | 0.6981 | -713.0 | -631.0 | |
| 13.47 | -19.00 | 9.25 | -19.00 | -12.86 | 47.01 | -39.80 | 115.65 | 0.6946 | -1086.1 | 999999 | |
| 2.01 | -19.00 | 1.39 | -19.00 | -13.20 | 46.62 | -40.19 | 115.89 | 0.7006 | -719.4 | 999999 | |
| 11.72 | -19.00 | 8.15 | -19.00 | -13.07 | 46.28 | -40.52 | 115.53 | 0.7038 | -875.2 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.68 | -14.10 | 45.94 | -40.86 | 116.69 | 0.7126 | -458.0 | -357.0 | |
| 0.00 | 0.79 | 0.00 | 0.56 | -14.06 | 45.66 | -41.14 | 116.49 | 0.7154 | -348.0 | -299.8 | |
| 0.00 | 1.57 | 0.00 | 1.11 | -13.90 | 45.66 | -41.15 | 116.28 | 0.7147 | -396.0 | -351.8 | |
| 26.86 | -19.00 | 18.73 | -19.00 | -12.62 | 45.88 | -40.92 | 114.73 | 0.7061 | -868.5 | 999999 | |
| 5.86 | -19.00 | 4.07 | -19.00 | -12.00 | 45.80 | -41.01 | 113.87 | 0.7042 | -774.6 | 999999 | |
| 5.34 | -19.00 | 3.70 | -19.00 | -11.60 | 45.75 | -41.06 | 113.31 | 0.7029 | -785.2 | 999999 | |
| 1.75 | -19.00 | 1.22 | -19.00 | -12.20 | 45.64 | -41.17 | 114.05 | 0.7069 | -637.0 | 999999 | |
| 1.05 | -19.00 | 0.74 | -19.00 | -12.06 | 45.38 | -41.43 | 113.74 | 0.7092 | -401.3 | 999999 | |
| 1.22 | -19.00 | 0.86 | -19.00 | -11.94 | 45.36 | -41.44 | 113.57 | 0.7088 | -616.2 | 999999 | |
| 0.00 | 1.14 | 0.00 | 0.81 | -11.78 | 44.57 | -42.24 | 112.96 | 0.7170 | 133.0 | 141.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
